NVIS PolyVision Ring Filters for LED Light Sources

NVIS Compliant per MIL-L-85762A and MIL-STD-3009 for SAE AS7788 Type VII Edge Lit Panels and other NVG Compatible Displays using Discrete 3mm or 5mm LEDs, or SMD Type LEDs

Part Number Table

PolyVision Ring Filter for LEDs Master List
Part NumberNVIS ColorFigureØA
Diameter
ØB
Diameter
D
Dimension
Overall
Length
L-65196-185-120Green AFigure 10.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.120 [3.0mm]
L-65196-185-130Green AFigure 10.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.130 [3.3mm]
L-65196-185-140Green AFigure 10.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.140 [3.6mm]
L-65196-185-150Green AFigure 10.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.150 [3.8mm]
L-65196-185-160Green AFigure 10.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.160 [4.1mm]
L-65196-185-170Green AFigure 10.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.170 [4.3mm]
L-65196-185-180Green AFigure 10.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.180 [4.6mm]
L-65196-185-190Green AFigure 10.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.190 [4.8mm]
L-65196-185-200Green AFigure 10.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.200 [5.1mm]
L-65196-210-120Green AFigure 10.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.120 [3.0mm]
L-65196-210-130Green AFigure 10.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.130 [3.3mm]
L-65196-210-140Green AFigure 10.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.140 [3.6mm]
L-65196-210-150Green AFigure 10.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.150 [3.8mm]
L-65196-210-160Green AFigure 10.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.160 [4.1mm]
L-65196-210-170Green AFigure 10.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.170 [4.3mm]
L-65196-210-180Green AFigure 10.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.180 [4.6mm]
L-65196-210-190Green AFigure 10.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.190 [4.8mm]
L-65196-210-200Green AFigure 10.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.200 [5.1mm]
L-65196-240-120Green AFigure 10.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.120 [3.0mm]
L-65196-240-130Green AFigure 10.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.130 [3.3mm]
L-65196-240-140Green AFigure 10.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.140 [3.6mm]
L-65196-240-150Green AFigure 10.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.150 [3.8mm]
L-65196-240-160Green AFigure 10.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.160 [4.1mm]
L-65196-240-170Green AFigure 10.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.170 [4.3mm]
L-65196-240-180Green AFigure 10.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.180 [4.6mm]
L-65196-240-190Green AFigure 10.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.190 [4.8mm]
L-65196-240-200Green AFigure 10.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.200 [5.1mm]
L-65196-250-120Green AFigure 10.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.120 [3.0mm]
L-65196-250-130Green AFigure 10.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.130 [3.3mm]
L-65196-250-140Green AFigure 10.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.140 [3.6mm]
L-65196-250-150Green AFigure 10.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.150 [3.8mm]
L-65196-250-160Green AFigure 10.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.160 [4.1mm]
L-65196-250-170Green AFigure 10.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.170 [4.3mm]
L-65196-250-180Green AFigure 10.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.180 [4.6mm]
L-65196-250-190Green AFigure 10.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.190 [4.8mm]
L-65196-250-200Green AFigure 10.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.200 [5.1mm]
L-65196-280-120Green AFigure 10.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.120 [3.0mm]
L-65196-280-130Green AFigure 10.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.130 [3.3mm]
L-65196-280-140Green AFigure 10.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.140 [3.6mm]
L-65196-280-150Green AFigure 10.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.150 [3.8mm]
L-65196-280-160Green AFigure 10.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.160 [4.1mm]
L-65196-280-170Green AFigure 10.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.170 [4.3mm]
L-65196-280-180Green AFigure 10.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.180 [4.6mm]
L-65196-280-190Green AFigure 10.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.190 [4.8mm]
L-65196-280-200Green AFigure 10.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.200 [5.1mm]
L-65330-185-120Green AFigure 10.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.120 [3.0mm]
L-65330-185-130Green AFigure 10.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.130 [3.3mm]
L-65330-185-140Green AFigure 10.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.140 [3.6mm]
L-65330-185-150Green AFigure 10.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.150 [3.8mm]
L-65330-185-160Green AFigure 10.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.160 [4.1mm]
L-65330-185-170Green AFigure 10.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.170 [4.3mm]
L-65330-185-180Green AFigure 10.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.180 [4.6mm]
L-65330-185-190Green AFigure 10.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.190 [4.8mm]
L-65330-185-200Green AFigure 10.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.200 [5.1mm]
L-65330-210-120Green AFigure 10.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.120 [3.0mm]
L-65330-210-130Green AFigure 10.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.130 [3.3mm]
L-65330-210-140Green AFigure 10.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.140 [3.6mm]
L-65330-210-150Green AFigure 10.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.150 [3.8mm]
L-65330-210-160Green AFigure 10.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.160 [4.1mm]
L-65330-210-170Green AFigure 10.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.170 [4.3mm]
L-65330-210-180Green AFigure 10.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.180 [4.6mm]
L-65330-210-190Green AFigure 10.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.190 [4.8mm]
L-65330-210-200Green AFigure 10.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.200 [5.1mm]
L-65330-240-120Green AFigure 10.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.120 [3.0mm]
L-65330-240-130Green AFigure 10.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.130 [3.3mm]
L-65330-240-140Green AFigure 10.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.140 [3.6mm]
L-65330-240-150Green AFigure 10.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.150 [3.8mm]
L-65330-240-160Green AFigure 10.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.160 [4.1mm]
L-65330-240-170Green AFigure 10.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.170 [4.3mm]
L-65330-240-180Green AFigure 10.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.180 [4.6mm]
L-65330-240-190Green AFigure 10.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.190 [4.8mm]
L-65330-240-200Green AFigure 10.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.200 [5.1mm]
L-65330-250-120Green AFigure 10.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.120 [3.0mm]
L-65330-250-130Green AFigure 10.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.130 [3.3mm]
L-65330-250-140Green AFigure 10.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.140 [3.6mm]
L-65330-250-150Green AFigure 10.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.150 [3.8mm]
L-65330-250-160Green AFigure 10.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.160 [4.1mm]
L-65330-250-170Green AFigure 10.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.170 [4.3mm]
L-65330-250-180Green AFigure 10.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.180 [4.6mm]
L-65330-250-190Green AFigure 10.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.190 [4.8mm]
L-65330-250-200Green AFigure 10.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.200 [5.1mm]
L-65330-280-120Green AFigure 10.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.120 [3.0mm]
L-65330-280-130Green AFigure 10.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.130 [3.3mm]
L-65330-280-140Green AFigure 10.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.140 [3.6mm]
L-65330-280-150Green AFigure 10.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.150 [3.8mm]
L-65330-280-160Green AFigure 10.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.160 [4.1mm]
L-65330-280-170Green AFigure 10.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.170 [4.3mm]
L-65330-280-180Green AFigure 10.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.180 [4.6mm]
L-65330-280-190Green AFigure 10.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.190 [4.8mm]
L-65330-280-200Green AFigure 10.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.200 [5.1mm]
L-65197-185-120Green BFigure 10.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.120 [3.0mm]
L-65197-185-130Green BFigure 10.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.130 [3.3mm]
L-65197-185-140Green BFigure 10.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.140 [3.6mm]
L-65197-185-150Green BFigure 10.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.150 [3.8mm]
L-65197-185-160Green BFigure 10.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.160 [4.1mm]
L-65197-185-170Green BFigure 10.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.170 [4.3mm]
L-65197-185-180Green BFigure 10.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.180 [4.6mm]
L-65197-185-190Green BFigure 10.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.190 [4.8mm]
L-65197-185-200Green BFigure 10.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.200 [5.1mm]
L-65197-210-120Green BFigure 10.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.120 [3.0mm]
L-65197-210-130Green BFigure 10.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.130 [3.3mm]
L-65197-210-140Green BFigure 10.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.140 [3.6mm]
L-65197-210-150Green BFigure 10.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.150 [3.8mm]
L-65197-210-160Green BFigure 10.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.160 [4.1mm]
L-65197-210-170Green BFigure 10.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.170 [4.3mm]
L-65197-210-180Green BFigure 10.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.180 [4.6mm]
L-65197-210-190Green BFigure 10.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.190 [4.8mm]
L-65197-210-200Green BFigure 10.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.200 [5.1mm]
L-65197-240-120Green BFigure 10.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.120 [3.0mm]
L-65197-240-130Green BFigure 10.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.130 [3.3mm]
L-65197-240-140Green BFigure 10.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.140 [3.6mm]
L-65197-240-150Green BFigure 10.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.150 [3.8mm]
L-65197-240-160Green BFigure 10.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.160 [4.1mm]
L-65197-240-170Green BFigure 10.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.170 [4.3mm]
L-65197-240-180Green BFigure 10.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.180 [4.6mm]
L-65197-240-190Green BFigure 10.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.190 [4.8mm]
L-65197-240-200Green BFigure 10.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.200 [5.1mm]
L-65197-250-120Green BFigure 10.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.120 [3.0mm]
L-65197-250-130Green BFigure 10.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.130 [3.3mm]
L-65197-250-140Green BFigure 10.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.140 [3.6mm]
L-65197-250-150Green BFigure 10.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.150 [3.8mm]
L-65197-250-160Green BFigure 10.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.160 [4.1mm]
L-65197-250-170Green BFigure 10.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.170 [4.3mm]
L-65197-250-180Green BFigure 10.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.180 [4.6mm]
L-65197-250-190Green BFigure 10.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.190 [4.8mm]
L-65197-250-200Green BFigure 10.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.200 [5.1mm]
L-65197-280-120Green BFigure 10.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.120 [3.0mm]
L-65197-280-130Green BFigure 10.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.130 [3.3mm]
L-65197-280-140Green BFigure 10.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.140 [3.6mm]
L-65197-280-150Green BFigure 10.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.150 [3.8mm]
L-65197-280-160Green BFigure 10.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.160 [4.1mm]
L-65197-280-170Green BFigure 10.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.170 [4.3mm]
L-65197-280-180Green BFigure 10.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.180 [4.6mm]
L-65197-280-190Green BFigure 10.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.190 [4.8mm]
L-65197-280-200Green BFigure 10.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.200 [5.1mm]
L-65250-185-120Green BFigure 10.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.120 [3.0mm]
L-65250-185-130Green BFigure 10.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.130 [3.3mm]
L-65250-185-140Green BFigure 10.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.140 [3.6mm]
L-65250-185-150Green BFigure 10.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.150 [3.8mm]
L-65250-185-160Green BFigure 10.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.160 [4.1mm]
L-65250-185-170Green BFigure 10.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.170 [4.3mm]
L-65250-185-180Green BFigure 10.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.180 [4.6mm]
L-65250-185-190Green BFigure 10.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.190 [4.8mm]
L-65250-185-200Green BFigure 10.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.200 [5.1mm]
L-65250-210-120Green BFigure 10.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.120 [3.0mm]
L-65250-210-130Green BFigure 10.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.130 [3.3mm]
L-65250-210-140Green BFigure 10.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.140 [3.6mm]
L-65250-210-150Green BFigure 10.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.150 [3.8mm]
L-65250-210-160Green BFigure 10.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.160 [4.1mm]
L-65250-210-170Green BFigure 10.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.170 [4.3mm]
L-65250-210-180Green BFigure 10.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.180 [4.6mm]
L-65250-210-190Green BFigure 10.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.190 [4.8mm]
L-65250-210-200Green BFigure 10.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.200 [5.1mm]
L-65250-240-120Green BFigure 10.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.120 [3.0mm]
L-65250-240-130Green BFigure 10.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.130 [3.3mm]
L-65250-240-140Green BFigure 10.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.140 [3.6mm]
L-65250-240-150Green BFigure 10.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.150 [3.8mm]
L-65250-240-160Green BFigure 10.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.160 [4.1mm]
L-65250-240-170Green BFigure 10.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.170 [4.3mm]
L-65250-240-180Green BFigure 10.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.180 [4.6mm]
L-65250-240-190Green BFigure 10.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.190 [4.8mm]
L-65250-240-200Green BFigure 10.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.200 [5.1mm]
L-65250-250-120Green BFigure 10.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.120 [3.0mm]
L-65250-250-130Green BFigure 10.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.130 [3.3mm]
L-65250-250-140Green BFigure 10.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.140 [3.6mm]
L-65250-250-150Green BFigure 10.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.150 [3.8mm]
L-65250-250-160Green BFigure 10.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.160 [4.1mm]
L-65250-250-170Green BFigure 10.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.170 [4.3mm]
L-65250-250-180Green BFigure 10.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.180 [4.6mm]
L-65250-250-190Green BFigure 10.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.190 [4.8mm]
L-65250-250-200Green BFigure 10.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.200 [5.1mm]
L-65250-280-120Green BFigure 10.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.120 [3.0mm]
L-65250-280-130Green BFigure 10.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.130 [3.3mm]
L-65250-280-140Green BFigure 10.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.140 [3.6mm]
L-65250-280-150Green BFigure 10.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.150 [3.8mm]
L-65250-280-160Green BFigure 10.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.160 [4.1mm]
L-65250-280-170Green BFigure 10.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.170 [4.3mm]
L-65250-280-180Green BFigure 10.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.180 [4.6mm]
L-65250-280-190Green BFigure 10.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.190 [4.8mm]
L-65250-280-200Green BFigure 10.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.200 [5.1mm]
L-65648-185-120WHITEFigure 10.185 [4.7mm]0.105 [2.7mm]0.040 [1.1mm]0.120 [3.0mm]
L-65648-185-130WHITEFigure 10.185 [4.7mm]0.105 [2.7mm]0.040 [1.1mm]0.130 [3.3mm]
L-65648-185-140WHITEFigure 10.185 [4.7mm]0.105 [2.7mm]0.040 [1.1mm]0.140 [3.6mm]
L-65648-185-150WHITEFigure 10.185 [4.7mm]0.105 [2.7mm]0.040 [1.1mm]0.150 [3.8mm]
L-65648-185-160WHITEFigure 10.185 [4.7mm]0.105 [2.7mm]0.040 [1.1mm]0.160 [4.1mm]
L-65648-185-170WHITEFigure 10.185 [4.7mm]0.105 [2.7mm]0.040 [1.1mm]0.170 [4.3mm]
L-65648-185-180WHITEFigure 10.185 [4.7mm]0.105 [2.7mm]0.040 [1.1mm]0.180 [4.6mm]
L-65648-185-190WHITEFigure 10.185 [4.7mm]0.105 [2.7mm]0.040 [1.1mm]0.190 [4.8mm]
L-65648-185-200WHITEFigure 10.185 [4.7mm]0.105 [2.7mm]0.040 [1.1mm]0.200 [5.1mm]
L-65648-210-120WHITEFigure 10.210 [5.3mm]0.130 [3.3mm]0.040 [1.1mm]0.120 [3.0mm]
L-65648-210-130WHITEFigure 10.210 [5.3mm]0.130 [3.3mm]0.040 [1.1mm]0.130 [3.3mm]
L-65648-210-140WHITEFigure 10.210 [5.3mm]0.130 [3.3mm]0.040 [1.1mm]0.140 [3.6mm]
L-65648-210-150WHITEFigure 10.210 [5.3mm]0.130 [3.3mm]0.040 [1.1mm]0.150 [3.8mm]
L-65648-210-160WHITEFigure 10.210 [5.3mm]0.130 [3.3mm]0.040 [1.1mm]0.160 [4.1mm]
L-65648-210-170WHITEFigure 10.210 [5.3mm]0.130 [3.3mm]0.040 [1.1mm]0.170 [4.3mm]
L-65648-210-180WHITEFigure 10.210 [5.3mm]0.130 [3.3mm]0.040 [1.1mm]0.180 [4.6mm]
L-65648-210-190WHITEFigure 10.210 [5.3mm]0.130 [3.3mm]0.040 [1.1mm]0.190 [4.8mm]
L-65648-210-200WHITEFigure 10.210 [5.3mm]0.130 [3.3mm]0.040 [1.1mm]0.200 [5.1mm]
L-65648-240-120WHITEFigure 10.240 [6.1mm]0.160 [4.1mm]0.040 [1.1mm]0.120 [3.0mm]
L-65648-240-130WHITEFigure 10.240 [6.1mm]0.160 [4.1mm]0.040 [1.1mm]0.130 [3.3mm]
L-65648-240-140WHITEFigure 10.240 [6.1mm]0.160 [4.1mm]0.040 [1.1mm]0.140 [3.6mm]
L-65648-240-150WHITEFigure 10.240 [6.1mm]0.160 [4.1mm]0.040 [1.1mm]0.150 [3.8mm]
L-65648-240-160WHITEFigure 10.240 [6.1mm]0.160 [4.1mm]0.040 [1.1mm]0.160 [4.1mm]
L-65648-240-170WHITEFigure 10.240 [6.1mm]0.160 [4.1mm]0.040 [1.1mm]0.170 [4.3mm]
L-65648-240-180WHITEFigure 10.240 [6.1mm]0.160 [4.1mm]0.040 [1.1mm]0.180 [4.6mm]
L-65648-240-190WHITEFigure 10.240 [6.1mm]0.160 [4.1mm]0.040 [1.1mm]0.190 [4.8mm]
L-65648-240-200WHITEFigure 10.240 [6.1mm]0.160 [4.1mm]0.040 [1.1mm]0.200 [5.1mm]
L-65648-250-120WHITEFigure 10.250 [6.3mm]0.170 [4.3mm]0.040 [1.1mm]0.120 [3.0mm]
L-65648-250-130WHITEFigure 10.250 [6.3mm]0.170 [4.3mm]0.040 [1.1mm]0.130 [3.3mm]
L-65648-250-140WHITEFigure 10.250 [6.3mm]0.170 [4.3mm]0.040 [1.1mm]0.140 [3.6mm]
L-65648-250-150WHITEFigure 10.250 [6.3mm]0.170 [4.3mm]0.040 [1.1mm]0.150 [3.8mm]
L-65648-250-160WHITEFigure 10.250 [6.3mm]0.170 [4.3mm]0.040 [1.1mm]0.160 [4.1mm]
L-65648-250-170WHITEFigure 10.250 [6.3mm]0.170 [4.3mm]0.040 [1.1mm]0.170 [4.3mm]
L-65648-250-180WHITEFigure 10.250 [6.3mm]0.170 [4.3mm]0.040 [1.1mm]0.180 [4.6mm]
L-65648-250-190WHITEFigure 10.250 [6.3mm]0.170 [4.3mm]0.040 [1.1mm]0.190 [4.8mm]
L-65648-250-200WHITEFigure 10.250 [6.3mm]0.170 [4.3mm]0.040 [1.1mm]0.200 [5.1mm]
L-65648-280-120WHITEFigure 10.280 [7.1mm]0.200 [5.1mm]0.040 [1.1mm]0.120 [3.0mm]
L-65648-280-130WHITEFigure 10.280 [7.1mm]0.200 [5.1mm]0.040 [1.1mm]0.130 [3.3mm]
L-65648-280-140WHITEFigure 10.280 [7.1mm]0.200 [5.1mm]0.040 [1.1mm]0.140 [3.6mm]
L-65648-280-150WHITEFigure 10.280 [7.1mm]0.200 [5.1mm]0.040 [1.1mm]0.150 [3.8mm]
L-65648-280-160WHITEFigure 10.280 [7.1mm]0.200 [5.1mm]0.040 [1.1mm]0.160 [4.1mm]
L-65648-280-170WHITEFigure 10.280 [7.1mm]0.200 [5.1mm]0.040 [1.1mm]0.170 [4.3mm]
L-65648-280-180WHITEFigure 10.280 [7.1mm]0.200 [5.1mm]0.040 [1.1mm]0.180 [4.6mm]
L-65648-280-190WHITEFigure 10.280 [7.1mm]0.200 [5.1mm]0.040 [1.1mm]0.190 [4.8mm]
L-65648-280-200WHITEFigure 10.280 [7.1mm]0.200 [5.1mm]0.040 [1.1mm]0.200 [5.1mm]
L-65951-185-120AMLCDFigure 10.185 [4.7mm]0.165 [4.2mm]0.020 [0.5mm]0.120 [3.0mm]
L-65951-185-130AMLCDFigure 10.185 [4.7mm]0.165 [4.2mm]0.020 [0.5mm]0.130 [3.3mm]
L-65951-185-140AMLCDFigure 10.185 [4.7mm]0.165 [4.2mm]0.020 [0.5mm]0.140 [3.6mm]
L-65951-185-150AMLCDFigure 10.185 [4.7mm]0.165 [4.2mm]0.020 [0.5mm]0.150 [3.8mm]
L-65951-185-160AMLCDFigure 10.185 [4.7mm]0.165 [4.2mm]0.020 [0.5mm]0.160 [4.1mm]
L-65951-185-170AMLCDFigure 10.185 [4.7mm]0.165 [4.2mm]0.020 [0.5mm]0.170 [4.3mm]
L-65951-185-180AMLCDFigure 10.185 [4.7mm]0.165 [4.2mm]0.020 [0.5mm]0.180 [4.6mm]
L-65951-185-190AMLCDFigure 10.185 [4.7mm]0.165 [4.2mm]0.020 [0.5mm]0.190 [4.8mm]
L-65951-185-200AMLCDFigure 10.185 [4.7mm]0.165 [4.2mm]0.020 [0.5mm]0.200 [5.1mm]
L-65951-210-120AMLCDFigure 10.210 [5.3mm]0.170 [4.3mm]0.020 [0.5mm]0.120 [3.0mm]
L-65951-210-130AMLCDFigure 10.210 [5.3mm]0.170 [4.3mm]0.020 [0.5mm]0.130 [3.3mm]
L-65951-210-140AMLCDFigure 10.210 [5.3mm]0.170 [4.3mm]0.020 [0.5mm]0.140 [3.6mm]
L-65951-210-150AMLCDFigure 10.210 [5.3mm]0.170 [4.3mm]0.020 [0.5mm]0.150 [3.8mm]
L-65951-210-160AMLCDFigure 10.210 [5.3mm]0.170 [4.3mm]0.020 [0.5mm]0.160 [4.1mm]
L-65951-210-170AMLCDFigure 10.210 [5.3mm]0.170 [4.3mm]0.020 [0.5mm]0.170 [4.3mm]
L-65951-210-180AMLCDFigure 10.210 [5.3mm]0.170 [4.3mm]0.020 [0.5mm]0.180 [4.6mm]
L-65951-210-190AMLCDFigure 10.210 [5.3mm]0.170 [4.3mm]0.020 [0.5mm]0.190 [4.8mm]
L-65951-210-200AMLCDFigure 10.210 [5.3mm]0.170 [4.3mm]0.020 [0.5mm]0.200 [5.1mm]
L-65951-240-120AMLCDFigure 10.240 [6.1mm]0.220 [5.6mm]0.020 [0.5mm]0.120 [3.0mm]
L-65951-240-130AMLCDFigure 10.240 [6.1mm]0.220 [5.6mm]0.020 [0.5mm]0.130 [3.3mm]
L-65951-240-140AMLCDFigure 10.240 [6.1mm]0.220 [5.6mm]0.020 [0.5mm]0.140 [3.6mm]
L-65951-240-150AMLCDFigure 10.240 [6.1mm]0.220 [5.6mm]0.020 [0.5mm]0.150 [3.8mm]
L-65951-240-160AMLCDFigure 10.240 [6.1mm]0.220 [5.6mm]0.020 [0.5mm]0.160 [4.1mm]
L-65951-240-170AMLCDFigure 10.240 [6.1mm]0.220 [5.6mm]0.020 [0.5mm]0.170 [4.3mm]
L-65951-240-180AMLCDFigure 10.240 [6.1mm]0.220 [5.6mm]0.020 [0.5mm]0.180 [4.6mm]
L-65951-240-190AMLCDFigure 10.240 [6.1mm]0.220 [5.6mm]0.020 [0.5mm]0.190 [4.8mm]
L-65951-240-200AMLCDFigure 10.240 [6.1mm]0.220 [5.6mm]0.020 [0.5mm]0.200 [5.1mm]
L-65951-250-120AMLCDFigure 10.250 [6.3mm]0.230 [5.8mm]0.020 [0.5mm]0.120 [3.0mm]
L-65951-250-130AMLCDFigure 10.250 [6.3mm]0.230 [5.8mm]0.020 [0.5mm]0.130 [3.3mm]
L-65951-250-140AMLCDFigure 10.250 [6.3mm]0.230 [5.8mm]0.020 [0.5mm]0.140 [3.6mm]
L-65951-250-150AMLCDFigure 10.250 [6.3mm]0.230 [5.8mm]0.020 [0.5mm]0.150 [3.8mm]
L-65951-250-160AMLCDFigure 10.250 [6.3mm]0.230 [5.8mm]0.020 [0.5mm]0.160 [4.1mm]
L-65951-250-170AMLCDFigure 10.250 [6.3mm]0.230 [5.8mm]0.020 [0.5mm]0.170 [4.3mm]
L-65951-250-180AMLCDFigure 10.250 [6.3mm]0.230 [5.8mm]0.020 [0.5mm]0.180 [4.6mm]
L-65951-250-190AMLCDFigure 10.250 [6.3mm]0.230 [5.8mm]0.020 [0.5mm]0.190 [4.8mm]
L-65951-250-200AMLCDFigure 10.250 [6.3mm]0.230 [5.8mm]0.020 [0.5mm]0.200 [5.1mm]
L-65951-280-120AMLCDFigure 10.280 [7.1mm]0.260 [6.6mm]0.020 [0.5mm]0.120 [3.0mm]
L-65951-280-130AMLCDFigure 10.280 [7.1mm]0.260 [6.6mm]0.020 [0.5mm]0.130 [3.3mm]
L-65951-280-140AMLCDFigure 10.280 [7.1mm]0.260 [6.6mm]0.020 [0.5mm]0.140 [3.6mm]
L-65951-280-150AMLCDFigure 10.280 [7.1mm]0.260 [6.6mm]0.020 [0.5mm]0.150 [3.8mm]
L-65951-280-160AMLCDFigure 10.280 [7.1mm]0.260 [6.6mm]0.020 [0.5mm]0.160 [4.1mm]
L-65951-280-170AMLCDFigure 10.280 [7.1mm]0.260 [6.6mm]0.020 [0.5mm]0.170 [4.3mm]
L-65951-280-180AMLCDFigure 10.280 [7.1mm]0.260 [6.6mm]0.020 [0.5mm]0.180 [4.6mm]
L-65951-280-190AMLCDFigure 10.280 [7.1mm]0.260 [6.6mm]0.020 [0.5mm]0.190 [4.8mm]
L-65951-280-200AMLCDFigure 10.280 [7.1mm]0.260 [6.6mm]0.020 [0.5mm]0.200 [5.1mm]
L-65401-185-120Yellow Class AFigure 10.185 [4.7mm]0.105 [2.7mm]0.040 [1.1mm]0.120 [3.0mm]
L-65401-185-130Yellow Class AFigure 10.185 [4.7mm]0.105 [2.7mm]0.040 [1.1mm]0.130 [3.3mm]
L-65401-185-140Yellow Class AFigure 10.185 [4.7mm]0.105 [2.7mm]0.040 [1.1mm]0.140 [3.6mm]
L-65401-185-150Yellow Class AFigure 10.185 [4.7mm]0.105 [2.7mm]0.040 [1.1mm]0.150 [3.8mm]
L-65401-185-160Yellow Class AFigure 10.185 [4.7mm]0.105 [2.7mm]0.040 [1.1mm]0.160 [4.1mm]
L-65401-185-170Yellow Class AFigure 10.185 [4.7mm]0.105 [2.7mm]0.040 [1.1mm]0.170 [4.3mm]
L-65401-185-180Yellow Class AFigure 10.185 [4.7mm]0.105 [2.7mm]0.040 [1.1mm]0.180 [4.6mm]
L-65401-185-190Yellow Class AFigure 10.185 [4.7mm]0.105 [2.7mm]0.040 [1.1mm]0.190 [4.8mm]
L-65401-185-200Yellow Class AFigure 10.185 [4.7mm]0.105 [2.7mm]0.040 [1.1mm]0.200 [5.1mm]
L-65401-210-120Yellow Class AFigure 10.210 [5.3mm]0.130 [3.3mm]0.040 [1.1mm]0.120 [3.0mm]
L-65401-210-130Yellow Class AFigure 10.210 [5.3mm]0.130 [3.3mm]0.040 [1.1mm]0.130 [3.3mm]
L-65401-210-140Yellow Class AFigure 10.210 [5.3mm]0.130 [3.3mm]0.040 [1.1mm]0.140 [3.6mm]
L-65401-210-150Yellow Class AFigure 10.210 [5.3mm]0.130 [3.3mm]0.040 [1.1mm]0.150 [3.8mm]
L-65401-210-160Yellow Class AFigure 10.210 [5.3mm]0.130 [3.3mm]0.040 [1.1mm]0.160 [4.1mm]
L-65401-210-170Yellow Class AFigure 10.210 [5.3mm]0.130 [3.3mm]0.040 [1.1mm]0.170 [4.3mm]
L-65401-210-180Yellow Class AFigure 10.210 [5.3mm]0.130 [3.3mm]0.040 [1.1mm]0.180 [4.6mm]
L-65401-210-190Yellow Class AFigure 10.210 [5.3mm]0.130 [3.3mm]0.040 [1.1mm]0.190 [4.8mm]
L-65401-210-200Yellow Class AFigure 10.210 [5.3mm]0.130 [3.3mm]0.040 [1.1mm]0.200 [5.1mm]
L-65401-240-120Yellow Class AFigure 10.240 [6.1mm]0.160 [4.1mm]0.040 [1.1mm]0.120 [3.0mm]
L-65401-240-130Yellow Class AFigure 10.240 [6.1mm]0.160 [4.1mm]0.040 [1.1mm]0.130 [3.3mm]
L-65401-240-140Yellow Class AFigure 10.240 [6.1mm]0.160 [4.1mm]0.040 [1.1mm]0.140 [3.6mm]
L-65401-240-150Yellow Class AFigure 10.240 [6.1mm]0.160 [4.1mm]0.040 [1.1mm]0.150 [3.8mm]
L-65401-240-160Yellow Class AFigure 10.240 [6.1mm]0.160 [4.1mm]0.040 [1.1mm]0.160 [4.1mm]
L-65401-240-170Yellow Class AFigure 10.240 [6.1mm]0.160 [4.1mm]0.040 [1.1mm]0.170 [4.3mm]
L-65401-240-180Yellow Class AFigure 10.240 [6.1mm]0.160 [4.1mm]0.040 [1.1mm]0.180 [4.6mm]
L-65401-240-190Yellow Class AFigure 10.240 [6.1mm]0.160 [4.1mm]0.040 [1.1mm]0.190 [4.8mm]
L-65401-240-200Yellow Class AFigure 10.240 [6.1mm]0.160 [4.1mm]0.040 [1.1mm]0.200 [5.1mm]
L-65401-250-120Yellow Class AFigure 10.250 [6.3mm]0.170 [4.3mm]0.040 [1.1mm]0.120 [3.0mm]
L-65401-250-130Yellow Class AFigure 10.250 [6.3mm]0.170 [4.3mm]0.040 [1.1mm]0.130 [3.3mm]
L-65401-250-140Yellow Class AFigure 10.250 [6.3mm]0.170 [4.3mm]0.040 [1.1mm]0.140 [3.6mm]
L-65401-250-150Yellow Class AFigure 10.250 [6.3mm]0.170 [4.3mm]0.040 [1.1mm]0.150 [3.8mm]
L-65401-250-160Yellow Class AFigure 10.250 [6.3mm]0.170 [4.3mm]0.040 [1.1mm]0.160 [4.1mm]
L-65401-250-170Yellow Class AFigure 10.250 [6.3mm]0.170 [4.3mm]0.040 [1.1mm]0.170 [4.3mm]
L-65401-250-180Yellow Class AFigure 10.250 [6.3mm]0.170 [4.3mm]0.040 [1.1mm]0.180 [4.6mm]
L-65401-250-190Yellow Class AFigure 10.250 [6.3mm]0.170 [4.3mm]0.040 [1.1mm]0.190 [4.8mm]
L-65401-250-200Yellow Class AFigure 10.250 [6.3mm]0.170 [4.3mm]0.040 [1.1mm]0.200 [5.1mm]
L-65401-280-120Yellow Class AFigure 10.280 [7.1mm]0.200 [5.1mm]0.040 [1.1mm]0.120 [3.0mm]
L-65401-280-130Yellow Class AFigure 10.280 [7.1mm]0.200 [5.1mm]0.040 [1.1mm]0.130 [3.3mm]
L-65401-280-140Yellow Class AFigure 10.280 [7.1mm]0.200 [5.1mm]0.040 [1.1mm]0.140 [3.6mm]
L-65401-280-150Yellow Class AFigure 10.280 [7.1mm]0.200 [5.1mm]0.040 [1.1mm]0.150 [3.8mm]
L-65401-280-160Yellow Class AFigure 10.280 [7.1mm]0.200 [5.1mm]0.040 [1.1mm]0.160 [4.1mm]
L-65401-280-170Yellow Class AFigure 10.280 [7.1mm]0.200 [5.1mm]0.040 [1.1mm]0.170 [4.3mm]
L-65401-280-180Yellow Class AFigure 10.280 [7.1mm]0.200 [5.1mm]0.040 [1.1mm]0.180 [4.6mm]
L-65401-280-190Yellow Class AFigure 10.280 [7.1mm]0.200 [5.1mm]0.040 [1.1mm]0.190 [4.8mm]
L-65401-280-200Yellow Class AFigure 10.280 [7.1mm]0.200 [5.1mm]0.040 [1.1mm]0.200 [5.1mm]
L-65402-185-120Yellow Class BFigure 10.185 [4.7mm]0.105 [2.7mm]0.040 [1.1mm]0.120 [3.0mm]
L-65402-185-130Yellow Class BFigure 10.185 [4.7mm]0.105 [2.7mm]0.040 [1.1mm]0.130 [3.3mm]
L-65402-185-140Yellow Class BFigure 10.185 [4.7mm]0.105 [2.7mm]0.040 [1.1mm]0.140 [3.6mm]
L-65402-185-150Yellow Class BFigure 10.185 [4.7mm]0.105 [2.7mm]0.040 [1.1mm]0.150 [3.8mm]
L-65402-185-160Yellow Class BFigure 10.185 [4.7mm]0.105 [2.7mm]0.040 [1.1mm]0.160 [4.1mm]
L-65402-185-170Yellow Class BFigure 10.185 [4.7mm]0.105 [2.7mm]0.040 [1.1mm]0.170 [4.3mm]
L-65402-185-180Yellow Class BFigure 10.185 [4.7mm]0.105 [2.7mm]0.040 [1.1mm]0.180 [4.6mm]
L-65402-185-190Yellow Class BFigure 10.185 [4.7mm]0.105 [2.7mm]0.040 [1.1mm]0.190 [4.8mm]
L-65402-185-200Yellow Class BFigure 10.185 [4.7mm]0.105 [2.7mm]0.040 [1.1mm]0.200 [5.1mm]
L-65402-210-120Yellow Class BFigure 10.210 [5.3mm]0.130 [3.3mm]0.040 [1.1mm]0.120 [3.0mm]
L-65402-210-130Yellow Class BFigure 10.210 [5.3mm]0.130 [3.3mm]0.040 [1.1mm]0.130 [3.3mm]
L-65402-210-140Yellow Class BFigure 10.210 [5.3mm]0.130 [3.3mm]0.040 [1.1mm]0.140 [3.6mm]
L-65402-210-150Yellow Class BFigure 10.210 [5.3mm]0.130 [3.3mm]0.040 [1.1mm]0.150 [3.8mm]
L-65402-210-160Yellow Class BFigure 10.210 [5.3mm]0.130 [3.3mm]0.040 [1.1mm]0.160 [4.1mm]
L-65402-210-170Yellow Class BFigure 10.210 [5.3mm]0.130 [3.3mm]0.040 [1.1mm]0.170 [4.3mm]
L-65402-210-180Yellow Class BFigure 10.210 [5.3mm]0.130 [3.3mm]0.040 [1.1mm]0.180 [4.6mm]
L-65402-210-190Yellow Class BFigure 10.210 [5.3mm]0.130 [3.3mm]0.040 [1.1mm]0.190 [4.8mm]
L-65402-210-200Yellow Class BFigure 10.210 [5.3mm]0.130 [3.3mm]0.040 [1.1mm]0.200 [5.1mm]
L-65402-240-120Yellow Class BFigure 10.240 [6.1mm]0.160 [4.1mm]0.040 [1.1mm]0.120 [3.0mm]
L-65402-240-130Yellow Class BFigure 10.240 [6.1mm]0.160 [4.1mm]0.040 [1.1mm]0.130 [3.3mm]
L-65402-240-140Yellow Class BFigure 10.240 [6.1mm]0.160 [4.1mm]0.040 [1.1mm]0.140 [3.6mm]
L-65402-240-150Yellow Class BFigure 10.240 [6.1mm]0.160 [4.1mm]0.040 [1.1mm]0.150 [3.8mm]
L-65402-240-160Yellow Class BFigure 10.240 [6.1mm]0.160 [4.1mm]0.040 [1.1mm]0.160 [4.1mm]
L-65402-240-170Yellow Class BFigure 10.240 [6.1mm]0.160 [4.1mm]0.040 [1.1mm]0.170 [4.3mm]
L-65402-240-180Yellow Class BFigure 10.240 [6.1mm]0.160 [4.1mm]0.040 [1.1mm]0.180 [4.6mm]
L-65402-240-190Yellow Class BFigure 10.240 [6.1mm]0.160 [4.1mm]0.040 [1.1mm]0.190 [4.8mm]
L-65402-240-200Yellow Class BFigure 10.240 [6.1mm]0.160 [4.1mm]0.040 [1.1mm]0.200 [5.1mm]
L-65402-250-120Yellow Class BFigure 10.250 [6.3mm]0.170 [4.3mm]0.040 [1.1mm]0.120 [3.0mm]
L-65402-250-130Yellow Class BFigure 10.250 [6.3mm]0.170 [4.3mm]0.040 [1.1mm]0.130 [3.3mm]
L-65402-250-140Yellow Class BFigure 10.250 [6.3mm]0.170 [4.3mm]0.040 [1.1mm]0.140 [3.6mm]
L-65402-250-150Yellow Class BFigure 10.250 [6.3mm]0.170 [4.3mm]0.040 [1.1mm]0.150 [3.8mm]
L-65402-250-160Yellow Class BFigure 10.250 [6.3mm]0.170 [4.3mm]0.040 [1.1mm]0.160 [4.1mm]
L-65402-250-170Yellow Class BFigure 10.250 [6.3mm]0.170 [4.3mm]0.040 [1.1mm]0.170 [4.3mm]
L-65402-250-180Yellow Class BFigure 10.250 [6.3mm]0.170 [4.3mm]0.040 [1.1mm]0.180 [4.6mm]
L-65402-250-190Yellow Class BFigure 10.250 [6.3mm]0.170 [4.3mm]0.040 [1.1mm]0.190 [4.8mm]
L-65402-250-200Yellow Class BFigure 10.250 [6.3mm]0.170 [4.3mm]0.040 [1.1mm]0.200 [5.1mm]
L-65402-280-120Yellow Class BFigure 10.280 [7.1mm]0.200 [5.1mm]0.040 [1.1mm]0.120 [3.0mm]
L-65402-280-130Yellow Class BFigure 10.280 [7.1mm]0.200 [5.1mm]0.040 [1.1mm]0.130 [3.3mm]
L-65402-280-140Yellow Class BFigure 10.280 [7.1mm]0.200 [5.1mm]0.040 [1.1mm]0.140 [3.6mm]
L-65402-280-150Yellow Class BFigure 10.280 [7.1mm]0.200 [5.1mm]0.040 [1.1mm]0.150 [3.8mm]
L-65402-280-160Yellow Class BFigure 10.280 [7.1mm]0.200 [5.1mm]0.040 [1.1mm]0.160 [4.1mm]
L-65402-280-170Yellow Class BFigure 10.280 [7.1mm]0.200 [5.1mm]0.040 [1.1mm]0.170 [4.3mm]
L-65402-280-180Yellow Class BFigure 10.280 [7.1mm]0.200 [5.1mm]0.040 [1.1mm]0.180 [4.6mm]
L-65402-280-190Yellow Class BFigure 10.280 [7.1mm]0.200 [5.1mm]0.040 [1.1mm]0.190 [4.8mm]
L-65402-280-200Yellow Class BFigure 10.280 [7.1mm]0.200 [5.1mm]0.040 [1.1mm]0.200 [5.1mm]
L-65403-185-120Red Class BFigure 10.185 [4.7mm]0.105 [2.7mm]0.020 [0.5mm]0.120 [3.0mm]
L-65403-185-130Red Class BFigure 10.185 [4.7mm]0.105 [2.7mm]0.020 [0.5mm]0.130 [3.3mm]
L-65403-185-140Red Class BFigure 10.185 [4.7mm]0.105 [2.7mm]0.020 [0.5mm]0.140 [3.6mm]
L-65403-185-150Red Class BFigure 10.185 [4.7mm]0.105 [2.7mm]0.020 [0.5mm]0.150 [3.8mm]
L-65403-185-160Red Class BFigure 10.185 [4.7mm]0.105 [2.7mm]0.020 [0.5mm]0.160 [4.1mm]
L-65403-185-170Red Class BFigure 10.185 [4.7mm]0.105 [2.7mm]0.020 [0.5mm]0.170 [4.3mm]
L-65403-185-180Red Class BFigure 10.185 [4.7mm]0.105 [2.7mm]0.020 [0.5mm]0.180 [4.6mm]
L-65403-185-190Red Class BFigure 10.185 [4.7mm]0.105 [2.7mm]0.020 [0.5mm]0.190 [4.8mm]
L-65403-185-200Red Class BFigure 10.185 [4.7mm]0.105 [2.7mm]0.020 [0.5mm]0.200 [5.1mm]
L-65403-210-120Red Class BFigure 10.210 [5.3mm]0.130 [3.3mm]0.020 [0.5mm]0.120 [3.0mm]
L-65403-210-130Red Class BFigure 10.210 [5.3mm]0.130 [3.3mm]0.020 [0.5mm]0.130 [3.3mm]
L-65403-210-140Red Class BFigure 10.210 [5.3mm]0.130 [3.3mm]0.020 [0.5mm]0.140 [3.6mm]
L-65403-210-150Red Class BFigure 10.210 [5.3mm]0.130 [3.3mm]0.020 [0.5mm]0.150 [3.8mm]
L-65403-210-160Red Class BFigure 10.210 [5.3mm]0.130 [3.3mm]0.020 [0.5mm]0.160 [4.1mm]
L-65403-210-170Red Class BFigure 10.210 [5.3mm]0.130 [3.3mm]0.020 [0.5mm]0.170 [4.3mm]
L-65403-210-180Red Class BFigure 10.210 [5.3mm]0.130 [3.3mm]0.020 [0.5mm]0.180 [4.6mm]
L-65403-210-190Red Class BFigure 10.210 [5.3mm]0.130 [3.3mm]0.020 [0.5mm]0.190 [4.8mm]
L-65403-210-200Red Class BFigure 10.210 [5.3mm]0.130 [3.3mm]0.020 [0.5mm]0.200 [5.1mm]
L-65403-240-120Red Class BFigure 10.240 [6.1mm]0.160 [4.1mm]0.020 [0.5mm]0.120 [3.0mm]
L-65403-240-130Red Class BFigure 10.240 [6.1mm]0.160 [4.1mm]0.020 [0.5mm]0.130 [3.3mm]
L-65403-240-140Red Class BFigure 10.240 [6.1mm]0.160 [4.1mm]0.020 [0.5mm]0.140 [3.6mm]
L-65403-240-150Red Class BFigure 10.240 [6.1mm]0.160 [4.1mm]0.020 [0.5mm]0.150 [3.8mm]
L-65403-240-160Red Class BFigure 10.240 [6.1mm]0.160 [4.1mm]0.020 [0.5mm]0.160 [4.1mm]
L-65403-240-170Red Class BFigure 10.240 [6.1mm]0.160 [4.1mm]0.020 [0.5mm]0.170 [4.3mm]
L-65403-240-180Red Class BFigure 10.240 [6.1mm]0.160 [4.1mm]0.020 [0.5mm]0.180 [4.6mm]
L-65403-240-190Red Class BFigure 10.240 [6.1mm]0.160 [4.1mm]0.020 [0.5mm]0.190 [4.8mm]
L-65403-240-200Red Class BFigure 10.240 [6.1mm]0.160 [4.1mm]0.020 [0.5mm]0.200 [5.1mm]
L-65403-250-120Red Class BFigure 10.250 [6.3mm]0.170 [4.3mm]0.020 [0.5mm]0.120 [3.0mm]
L-65403-250-130Red Class BFigure 10.250 [6.3mm]0.170 [4.3mm]0.020 [0.5mm]0.130 [3.3mm]
L-65403-250-140Red Class BFigure 10.250 [6.3mm]0.170 [4.3mm]0.020 [0.5mm]0.140 [3.6mm]
L-65403-250-150Red Class BFigure 10.250 [6.3mm]0.170 [4.3mm]0.020 [0.5mm]0.150 [3.8mm]
L-65403-250-160Red Class BFigure 10.250 [6.3mm]0.170 [4.3mm]0.020 [0.5mm]0.160 [4.1mm]
L-65403-250-170Red Class BFigure 10.250 [6.3mm]0.170 [4.3mm]0.020 [0.5mm]0.170 [4.3mm]
L-65403-250-180Red Class BFigure 10.250 [6.3mm]0.170 [4.3mm]0.020 [0.5mm]0.180 [4.6mm]
L-65403-250-190Red Class BFigure 10.250 [6.3mm]0.170 [4.3mm]0.020 [0.5mm]0.190 [4.8mm]
L-65403-250-200Red Class BFigure 10.250 [6.3mm]0.170 [4.3mm]0.020 [0.5mm]0.200 [5.1mm]
L-65403-280-120Red Class BFigure 10.280 [7.1mm]0.200 [5.1mm]0.020 [0.5mm]0.120 [3.0mm]
L-65403-280-130Red Class BFigure 10.280 [7.1mm]0.200 [5.1mm]0.020 [0.5mm]0.130 [3.3mm]
L-65403-280-140Red Class BFigure 10.280 [7.1mm]0.200 [5.1mm]0.020 [0.5mm]0.140 [3.6mm]
L-65403-280-150Red Class BFigure 10.280 [7.1mm]0.200 [5.1mm]0.020 [0.5mm]0.150 [3.8mm]
L-65403-280-160Red Class BFigure 10.280 [7.1mm]0.200 [5.1mm]0.020 [0.5mm]0.160 [4.1mm]
L-65403-280-170Red Class BFigure 10.280 [7.1mm]0.200 [5.1mm]0.020 [0.5mm]0.170 [4.3mm]
L-65403-280-180Red Class BFigure 10.280 [7.1mm]0.200 [5.1mm]0.020 [0.5mm]0.180 [4.6mm]
L-65403-280-190Red Class BFigure 10.280 [7.1mm]0.200 [5.1mm]0.020 [0.5mm]0.190 [4.8mm]
L-65403-280-200Red Class BFigure 10.280 [7.1mm]0.200 [5.1mm]0.020 [0.5mm]0.200 [5.1mm]
L-65196-185-120-DGreen AFigure 20.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.120 [3.0mm]
L-65196-185-130-DGreen AFigure 20.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.130 [3.3mm]
L-65196-185-140-DGreen AFigure 20.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.140 [3.6mm]
L-65196-185-150-DGreen AFigure 20.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.150 [3.8mm]
L-65196-185-160-DGreen AFigure 20.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.160 [4.1mm]
L-65196-185-170-DGreen AFigure 20.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.170 [4.3mm]
L-65196-185-180-DGreen AFigure 20.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.180 [4.6mm]
L-65196-185-190-DGreen AFigure 20.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.190 [4.8mm]
L-65196-185-200-DGreen AFigure 20.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.200 [5.1mm]
L-65196-210-120-DGreen AFigure 20.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.120 [3.0mm]
L-65196-210-130-DGreen AFigure 20.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.130 [3.3mm]
L-65196-210-140-DGreen AFigure 20.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.140 [3.6mm]
L-65196-210-150-DGreen AFigure 20.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.150 [3.8mm]
L-65196-210-160-DGreen AFigure 20.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.160 [4.1mm]
L-65196-210-170-DGreen AFigure 20.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.170 [4.3mm]
L-65196-210-180-DGreen AFigure 20.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.180 [4.6mm]
L-65196-210-190-DGreen AFigure 20.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.190 [4.8mm]
L-65196-210-200-DGreen AFigure 20.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.200 [5.1mm]
L-65196-240-120-DGreen AFigure 20.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.120 [3.0mm]
L-65196-240-130-DGreen AFigure 20.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.130 [3.3mm]
L-65196-240-140-DGreen AFigure 20.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.140 [3.6mm]
L-65196-240-150-DGreen AFigure 20.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.150 [3.8mm]
L-65196-240-160-DGreen AFigure 20.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.160 [4.1mm]
L-65196-240-170-DGreen AFigure 20.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.170 [4.3mm]
L-65196-240-180-DGreen AFigure 20.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.180 [4.6mm]
L-65196-240-190-DGreen AFigure 20.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.190 [4.8mm]
L-65196-240-200-DGreen AFigure 20.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.200 [5.1mm]
L-65196-250-120-DGreen AFigure 20.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.120 [3.0mm]
L-65196-250-130-DGreen AFigure 20.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.130 [3.3mm]
L-65196-250-140-DGreen AFigure 20.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.140 [3.6mm]
L-65196-250-150-DGreen AFigure 20.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.150 [3.8mm]
L-65196-250-160-DGreen AFigure 20.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.160 [4.1mm]
L-65196-250-170-DGreen AFigure 20.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.170 [4.3mm]
L-65196-250-180-DGreen AFigure 20.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.180 [4.6mm]
L-65196-250-190-DGreen AFigure 20.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.190 [4.8mm]
L-65196-250-200-DGreen AFigure 20.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.200 [5.1mm]
L-65196-280-120-DGreen AFigure 20.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.120 [3.0mm]
L-65196-280-130-DGreen AFigure 20.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.130 [3.3mm]
L-65196-280-140-DGreen AFigure 20.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.140 [3.6mm]
L-65196-280-150-DGreen AFigure 20.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.150 [3.8mm]
L-65196-280-160-DGreen AFigure 20.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.160 [4.1mm]
L-65196-280-170-DGreen AFigure 20.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.170 [4.3mm]
L-65196-280-180-DGreen AFigure 20.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.180 [4.6mm]
L-65196-280-190-DGreen AFigure 20.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.190 [4.8mm]
L-65196-280-200-DGreen AFigure 20.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.200 [5.1mm]
L-65330-185-120-DGreen AFigure 20.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.120 [3.0mm]
L-65330-185-130-DGreen AFigure 20.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.130 [3.3mm]
L-65330-185-140-DGreen AFigure 20.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.140 [3.6mm]
L-65330-185-150-DGreen AFigure 20.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.150 [3.8mm]
L-65330-185-160-DGreen AFigure 20.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.160 [4.1mm]
L-65330-185-170-DGreen AFigure 20.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.170 [4.3mm]
L-65330-185-180-DGreen AFigure 20.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.180 [4.6mm]
L-65330-185-190-DGreen AFigure 20.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.190 [4.8mm]
L-65330-185-200-DGreen AFigure 20.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.200 [5.1mm]
L-65330-210-120-DGreen AFigure 20.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.120 [3.0mm]
L-65330-210-130-DGreen AFigure 20.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.130 [3.3mm]
L-65330-210-140-DGreen AFigure 20.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.140 [3.6mm]
L-65330-210-150-DGreen AFigure 20.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.150 [3.8mm]
L-65330-210-160-DGreen AFigure 20.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.160 [4.1mm]
L-65330-210-170-DGreen AFigure 20.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.170 [4.3mm]
L-65330-210-180-DGreen AFigure 20.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.180 [4.6mm]
L-65330-210-190-DGreen AFigure 20.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.190 [4.8mm]
L-65330-210-200-DGreen AFigure 20.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.200 [5.1mm]
L-65330-240-120-DGreen AFigure 20.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.120 [3.0mm]
L-65330-240-130-DGreen AFigure 20.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.130 [3.3mm]
L-65330-240-140-DGreen AFigure 20.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.140 [3.6mm]
L-65330-240-150-DGreen AFigure 20.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.150 [3.8mm]
L-65330-240-160-DGreen AFigure 20.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.160 [4.1mm]
L-65330-240-170-DGreen AFigure 20.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.170 [4.3mm]
L-65330-240-180-DGreen AFigure 20.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.180 [4.6mm]
L-65330-240-190-DGreen AFigure 20.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.190 [4.8mm]
L-65330-240-200-DGreen AFigure 20.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.200 [5.1mm]
L-65330-250-120-DGreen AFigure 20.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.120 [3.0mm]
L-65330-250-130-DGreen AFigure 20.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.130 [3.3mm]
L-65330-250-140-DGreen AFigure 20.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.140 [3.6mm]
L-65330-250-150-DGreen AFigure 20.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.150 [3.8mm]
L-65330-250-160-DGreen AFigure 20.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.160 [4.1mm]
L-65330-250-170-DGreen AFigure 20.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.170 [4.3mm]
L-65330-250-180-DGreen AFigure 20.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.180 [4.6mm]
L-65330-250-190-DGreen AFigure 20.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.190 [4.8mm]
L-65330-250-200-DGreen AFigure 20.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.200 [5.1mm]
L-65330-280-120-DGreen AFigure 20.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.120 [3.0mm]
L-65330-280-130-DGreen AFigure 20.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.130 [3.3mm]
L-65330-280-140-DGreen AFigure 20.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.140 [3.6mm]
L-65330-280-150-DGreen AFigure 20.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.150 [3.8mm]
L-65330-280-160-DGreen AFigure 20.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.160 [4.1mm]
L-65330-280-170-DGreen AFigure 20.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.170 [4.3mm]
L-65330-280-180-DGreen AFigure 20.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.180 [4.6mm]
L-65330-280-190-DGreen AFigure 20.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.190 [4.8mm]
L-65330-280-200-DGreen AFigure 20.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.200 [5.1mm]
L-65197-185-120-DGreen BFigure 20.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.120 [3.0mm]
L-65197-185-130-DGreen BFigure 20.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.130 [3.3mm]
L-65197-185-140-DGreen BFigure 20.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.140 [3.6mm]
L-65197-185-150-DGreen BFigure 20.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.150 [3.8mm]
L-65197-185-160-DGreen BFigure 20.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.160 [4.1mm]
L-65197-185-170-DGreen BFigure 20.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.170 [4.3mm]
L-65197-185-180-DGreen BFigure 20.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.180 [4.6mm]
L-65197-185-190-DGreen BFigure 20.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.190 [4.8mm]
L-65197-185-200-DGreen BFigure 20.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.200 [5.1mm]
L-65197-210-120-DGreen BFigure 20.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.120 [3.0mm]
L-65197-210-130-DGreen BFigure 20.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.130 [3.3mm]
L-65197-210-140-DGreen BFigure 20.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.140 [3.6mm]
L-65197-210-150-DGreen BFigure 20.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.150 [3.8mm]
L-65197-210-160-DGreen BFigure 20.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.160 [4.1mm]
L-65197-210-170-DGreen BFigure 20.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.170 [4.3mm]
L-65197-210-180-DGreen BFigure 20.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.180 [4.6mm]
L-65197-210-190-DGreen BFigure 20.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.190 [4.8mm]
L-65197-210-200-DGreen BFigure 20.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.200 [5.1mm]
L-65197-240-120-DGreen BFigure 20.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.120 [3.0mm]
L-65197-240-130-DGreen BFigure 20.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.130 [3.3mm]
L-65197-240-140-DGreen BFigure 20.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.140 [3.6mm]
L-65197-240-150-DGreen BFigure 20.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.150 [3.8mm]
L-65197-240-160-DGreen BFigure 20.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.160 [4.1mm]
L-65197-240-170-DGreen BFigure 20.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.170 [4.3mm]
L-65197-240-180-DGreen BFigure 20.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.180 [4.6mm]
L-65197-240-190-DGreen BFigure 20.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.190 [4.8mm]
L-65197-240-200-DGreen BFigure 20.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.200 [5.1mm]
L-65197-250-120-DGreen BFigure 20.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.120 [3.0mm]
L-65197-250-130-DGreen BFigure 20.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.130 [3.3mm]
L-65197-250-140-DGreen BFigure 20.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.140 [3.6mm]
L-65197-250-150-DGreen BFigure 20.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.150 [3.8mm]
L-65197-250-160-DGreen BFigure 20.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.160 [4.1mm]
L-65197-250-170-DGreen BFigure 20.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.170 [4.3mm]
L-65197-250-180-DGreen BFigure 20.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.180 [4.6mm]
L-65197-250-190-DGreen BFigure 20.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.190 [4.8mm]
L-65197-250-200-DGreen BFigure 20.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.200 [5.1mm]
L-65197-280-120-DGreen BFigure 20.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.120 [3.0mm]
L-65197-280-130-DGreen BFigure 20.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.130 [3.3mm]
L-65197-280-140-DGreen BFigure 20.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.140 [3.6mm]
L-65197-280-150-DGreen BFigure 20.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.150 [3.8mm]
L-65197-280-160-DGreen BFigure 20.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.160 [4.1mm]
L-65197-280-170-DGreen BFigure 20.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.170 [4.3mm]
L-65197-280-180-DGreen BFigure 20.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.180 [4.6mm]
L-65197-280-190-DGreen BFigure 20.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.190 [4.8mm]
L-65197-280-200-DGreen BFigure 20.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.200 [5.1mm]
L-65250-185-120-DGreen BFigure 20.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.120 [3.0mm]
L-65250-185-130-DGreen BFigure 20.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.130 [3.3mm]
L-65250-185-140-DGreen BFigure 20.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.140 [3.6mm]
L-65250-185-150-DGreen BFigure 20.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.150 [3.8mm]
L-65250-185-160-DGreen BFigure 20.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.160 [4.1mm]
L-65250-185-170-DGreen BFigure 20.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.170 [4.3mm]
L-65250-185-180-DGreen BFigure 20.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.180 [4.6mm]
L-65250-185-190-DGreen BFigure 20.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.190 [4.8mm]
L-65250-185-200-DGreen BFigure 20.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.200 [5.1mm]
L-65250-210-120-DGreen BFigure 20.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.120 [3.0mm]
L-65250-210-130-DGreen BFigure 20.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.130 [3.3mm]
L-65250-210-140-DGreen BFigure 20.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.140 [3.6mm]
L-65250-210-150-DGreen BFigure 20.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.150 [3.8mm]
L-65250-210-160-DGreen BFigure 20.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.160 [4.1mm]
L-65250-210-170-DGreen BFigure 20.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.170 [4.3mm]
L-65250-210-180-DGreen BFigure 20.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.180 [4.6mm]
L-65250-210-190-DGreen BFigure 20.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.190 [4.8mm]
L-65250-210-200-DGreen BFigure 20.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.200 [5.1mm]
L-65250-240-120-DGreen BFigure 20.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.120 [3.0mm]
L-65250-240-130-DGreen BFigure 20.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.130 [3.3mm]
L-65250-240-140-DGreen BFigure 20.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.140 [3.6mm]
L-65250-240-150-DGreen BFigure 20.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.150 [3.8mm]
L-65250-240-160-DGreen BFigure 20.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.160 [4.1mm]
L-65250-240-170-DGreen BFigure 20.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.170 [4.3mm]
L-65250-240-180-DGreen BFigure 20.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.180 [4.6mm]
L-65250-240-190-DGreen BFigure 20.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.190 [4.8mm]
L-65250-240-200-DGreen BFigure 20.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.200 [5.1mm]
L-65250-250-120-DGreen BFigure 20.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.120 [3.0mm]
L-65250-250-130-DGreen BFigure 20.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.130 [3.3mm]
L-65250-250-140-DGreen BFigure 20.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.140 [3.6mm]
L-65250-250-150-DGreen BFigure 20.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.150 [3.8mm]
L-65250-250-160-DGreen BFigure 20.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.160 [4.1mm]
L-65250-250-170-DGreen BFigure 20.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.170 [4.3mm]
L-65250-250-180-DGreen BFigure 20.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.180 [4.6mm]
L-65250-250-190-DGreen BFigure 20.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.190 [4.8mm]
L-65250-250-200-DGreen BFigure 20.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.200 [5.1mm]
L-65250-280-120-DGreen BFigure 20.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.120 [3.0mm]
L-65250-280-130-DGreen BFigure 20.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.130 [3.3mm]
L-65250-280-140-DGreen BFigure 20.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.140 [3.6mm]
L-65250-280-150-DGreen BFigure 20.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.150 [3.8mm]
L-65250-280-160-DGreen BFigure 20.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.160 [4.1mm]
L-65250-280-170-DGreen BFigure 20.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.170 [4.3mm]
L-65250-280-180-DGreen BFigure 20.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.180 [4.6mm]
L-65250-280-190-DGreen BFigure 20.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.190 [4.8mm]
L-65250-280-200-DGreen BFigure 20.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.200 [5.1mm]
L-65648-185-120-DWHITEFigure 20.185 [4.7mm]0.105 [2.7mm]0.040 [1.1mm]0.120 [3.0mm]
L-65648-185-130-DWHITEFigure 20.185 [4.7mm]0.105 [2.7mm]0.040 [1.1mm]0.130 [3.3mm]
L-65648-185-140-DWHITEFigure 20.185 [4.7mm]0.105 [2.7mm]0.040 [1.1mm]0.140 [3.6mm]
L-65648-185-150-DWHITEFigure 20.185 [4.7mm]0.105 [2.7mm]0.040 [1.1mm]0.150 [3.8mm]
L-65648-185-160-DWHITEFigure 20.185 [4.7mm]0.105 [2.7mm]0.040 [1.1mm]0.160 [4.1mm]
L-65648-185-170-DWHITEFigure 20.185 [4.7mm]0.105 [2.7mm]0.040 [1.1mm]0.170 [4.3mm]
L-65648-185-180-DWHITEFigure 20.185 [4.7mm]0.105 [2.7mm]0.040 [1.1mm]0.180 [4.6mm]
L-65648-185-190-DWHITEFigure 20.185 [4.7mm]0.105 [2.7mm]0.040 [1.1mm]0.190 [4.8mm]
L-65648-185-200-DWHITEFigure 20.185 [4.7mm]0.105 [2.7mm]0.040 [1.1mm]0.200 [5.1mm]
L-65648-210-120-DWHITEFigure 20.210 [5.3mm]0.130 [3.3mm]0.040 [1.1mm]0.120 [3.0mm]
L-65648-210-130-DWHITEFigure 20.210 [5.3mm]0.130 [3.3mm]0.040 [1.1mm]0.130 [3.3mm]
L-65648-210-140-DWHITEFigure 20.210 [5.3mm]0.130 [3.3mm]0.040 [1.1mm]0.140 [3.6mm]
L-65648-210-150-DWHITEFigure 20.210 [5.3mm]0.130 [3.3mm]0.040 [1.1mm]0.150 [3.8mm]
L-65648-210-160-DWHITEFigure 20.210 [5.3mm]0.130 [3.3mm]0.040 [1.1mm]0.160 [4.1mm]
L-65648-210-170-DWHITEFigure 20.210 [5.3mm]0.130 [3.3mm]0.040 [1.1mm]0.170 [4.3mm]
L-65648-210-180-DWHITEFigure 20.210 [5.3mm]0.130 [3.3mm]0.040 [1.1mm]0.180 [4.6mm]
L-65648-210-190-DWHITEFigure 20.210 [5.3mm]0.130 [3.3mm]0.040 [1.1mm]0.190 [4.8mm]
L-65648-210-200-DWHITEFigure 20.210 [5.3mm]0.130 [3.3mm]0.040 [1.1mm]0.200 [5.1mm]
L-65648-240-120-DWHITEFigure 20.240 [6.1mm]0.160 [4.1mm]0.040 [1.1mm]0.120 [3.0mm]
L-65648-240-130-DWHITEFigure 20.240 [6.1mm]0.160 [4.1mm]0.040 [1.1mm]0.130 [3.3mm]
L-65648-240-140-DWHITEFigure 20.240 [6.1mm]0.160 [4.1mm]0.040 [1.1mm]0.140 [3.6mm]
L-65648-240-150-DWHITEFigure 20.240 [6.1mm]0.160 [4.1mm]0.040 [1.1mm]0.150 [3.8mm]
L-65648-240-160-DWHITEFigure 20.240 [6.1mm]0.160 [4.1mm]0.040 [1.1mm]0.160 [4.1mm]
L-65648-240-170-DWHITEFigure 20.240 [6.1mm]0.160 [4.1mm]0.040 [1.1mm]0.170 [4.3mm]
L-65648-240-180-DWHITEFigure 20.240 [6.1mm]0.160 [4.1mm]0.040 [1.1mm]0.180 [4.6mm]
L-65648-240-190-DWHITEFigure 20.240 [6.1mm]0.160 [4.1mm]0.040 [1.1mm]0.190 [4.8mm]
L-65648-240-200-DWHITEFigure 20.240 [6.1mm]0.160 [4.1mm]0.040 [1.1mm]0.200 [5.1mm]
L-65648-250-120-DWHITEFigure 20.250 [6.3mm]0.170 [4.3mm]0.040 [1.1mm]0.120 [3.0mm]
L-65648-250-130-DWHITEFigure 20.250 [6.3mm]0.170 [4.3mm]0.040 [1.1mm]0.130 [3.3mm]
L-65648-250-140-DWHITEFigure 20.250 [6.3mm]0.170 [4.3mm]0.040 [1.1mm]0.140 [3.6mm]
L-65648-250-150-DWHITEFigure 20.250 [6.3mm]0.170 [4.3mm]0.040 [1.1mm]0.150 [3.8mm]
L-65648-250-160-DWHITEFigure 20.250 [6.3mm]0.170 [4.3mm]0.040 [1.1mm]0.160 [4.1mm]
L-65648-250-170-DWHITEFigure 20.250 [6.3mm]0.170 [4.3mm]0.040 [1.1mm]0.170 [4.3mm]
L-65648-250-180-DWHITEFigure 20.250 [6.3mm]0.170 [4.3mm]0.040 [1.1mm]0.180 [4.6mm]
L-65648-250-190-DWHITEFigure 20.250 [6.3mm]0.170 [4.3mm]0.040 [1.1mm]0.190 [4.8mm]
L-65648-250-200-DWHITEFigure 20.250 [6.3mm]0.170 [4.3mm]0.040 [1.1mm]0.200 [5.1mm]
L-65648-280-120-DWHITEFigure 20.280 [7.1mm]0.200 [5.1mm]0.040 [1.1mm]0.120 [3.0mm]
L-65648-280-130-DWHITEFigure 20.280 [7.1mm]0.200 [5.1mm]0.040 [1.1mm]0.130 [3.3mm]
L-65648-280-140-DWHITEFigure 20.280 [7.1mm]0.200 [5.1mm]0.040 [1.1mm]0.140 [3.6mm]
L-65648-280-150-DWHITEFigure 20.280 [7.1mm]0.200 [5.1mm]0.040 [1.1mm]0.150 [3.8mm]
L-65648-280-160-DWHITEFigure 20.280 [7.1mm]0.200 [5.1mm]0.040 [1.1mm]0.160 [4.1mm]
L-65648-280-170-DWHITEFigure 20.280 [7.1mm]0.200 [5.1mm]0.040 [1.1mm]0.170 [4.3mm]
L-65648-280-180-DWHITEFigure 20.280 [7.1mm]0.200 [5.1mm]0.040 [1.1mm]0.180 [4.6mm]
L-65648-280-190-DWHITEFigure 20.280 [7.1mm]0.200 [5.1mm]0.040 [1.1mm]0.190 [4.8mm]
L-65648-280-200-DWHITEFigure 20.280 [7.1mm]0.200 [5.1mm]0.040 [1.1mm]0.200 [5.1mm]
L-65951-185-120-DAMLCDFigure 20.185 [4.7mm]0.165 [4.2mm]0.020 [0.5mm]0.120 [3.0mm]
L-65951-185-130-DAMLCDFigure 20.185 [4.7mm]0.165 [4.2mm]0.020 [0.5mm]0.130 [3.3mm]
L-65951-185-140-DAMLCDFigure 20.185 [4.7mm]0.165 [4.2mm]0.020 [0.5mm]0.140 [3.6mm]
L-65951-185-150-DAMLCDFigure 20.185 [4.7mm]0.165 [4.2mm]0.020 [0.5mm]0.150 [3.8mm]
L-65951-185-160-DAMLCDFigure 20.185 [4.7mm]0.165 [4.2mm]0.020 [0.5mm]0.160 [4.1mm]
L-65951-185-170-DAMLCDFigure 20.185 [4.7mm]0.165 [4.2mm]0.020 [0.5mm]0.170 [4.3mm]
L-65951-185-180-DAMLCDFigure 20.185 [4.7mm]0.165 [4.2mm]0.020 [0.5mm]0.180 [4.6mm]
L-65951-185-190-DAMLCDFigure 20.185 [4.7mm]0.165 [4.2mm]0.020 [0.5mm]0.190 [4.8mm]
L-65951-185-200-DAMLCDFigure 20.185 [4.7mm]0.165 [4.2mm]0.020 [0.5mm]0.200 [5.1mm]
L-65951-210-120-DAMLCDFigure 20.210 [5.3mm]0.170 [4.3mm]0.020 [0.5mm]0.120 [3.0mm]
L-65951-210-130-DAMLCDFigure 20.210 [5.3mm]0.170 [4.3mm]0.020 [0.5mm]0.130 [3.3mm]
L-65951-210-140-DAMLCDFigure 20.210 [5.3mm]0.170 [4.3mm]0.020 [0.5mm]0.140 [3.6mm]
L-65951-210-150-DAMLCDFigure 20.210 [5.3mm]0.170 [4.3mm]0.020 [0.5mm]0.150 [3.8mm]
L-65951-210-160-DAMLCDFigure 20.210 [5.3mm]0.170 [4.3mm]0.020 [0.5mm]0.160 [4.1mm]
L-65951-210-170-DAMLCDFigure 20.210 [5.3mm]0.170 [4.3mm]0.020 [0.5mm]0.170 [4.3mm]
L-65951-210-180-DAMLCDFigure 20.210 [5.3mm]0.170 [4.3mm]0.020 [0.5mm]0.180 [4.6mm]
L-65951-210-190-DAMLCDFigure 20.210 [5.3mm]0.170 [4.3mm]0.020 [0.5mm]0.190 [4.8mm]
L-65951-210-200-DAMLCDFigure 20.210 [5.3mm]0.170 [4.3mm]0.020 [0.5mm]0.200 [5.1mm]
L-65951-240-120-DAMLCDFigure 20.240 [6.1mm]0.220 [5.6mm]0.020 [0.5mm]0.120 [3.0mm]
L-65951-240-130-DAMLCDFigure 20.240 [6.1mm]0.220 [5.6mm]0.020 [0.5mm]0.130 [3.3mm]
L-65951-240-140-DAMLCDFigure 20.240 [6.1mm]0.220 [5.6mm]0.020 [0.5mm]0.140 [3.6mm]
L-65951-240-150-DAMLCDFigure 20.240 [6.1mm]0.220 [5.6mm]0.020 [0.5mm]0.150 [3.8mm]
L-65951-240-160-DAMLCDFigure 20.240 [6.1mm]0.220 [5.6mm]0.020 [0.5mm]0.160 [4.1mm]
L-65951-240-170-DAMLCDFigure 20.240 [6.1mm]0.220 [5.6mm]0.020 [0.5mm]0.170 [4.3mm]
L-65951-240-180-DAMLCDFigure 20.240 [6.1mm]0.220 [5.6mm]0.020 [0.5mm]0.180 [4.6mm]
L-65951-240-190-DAMLCDFigure 20.240 [6.1mm]0.220 [5.6mm]0.020 [0.5mm]0.190 [4.8mm]
L-65951-240-200-DAMLCDFigure 20.240 [6.1mm]0.220 [5.6mm]0.020 [0.5mm]0.200 [5.1mm]
L-65951-250-120-DAMLCDFigure 20.250 [6.3mm]0.230 [5.8mm]0.020 [0.5mm]0.120 [3.0mm]
L-65951-250-130-DAMLCDFigure 20.250 [6.3mm]0.230 [5.8mm]0.020 [0.5mm]0.130 [3.3mm]
L-65951-250-140-DAMLCDFigure 20.250 [6.3mm]0.230 [5.8mm]0.020 [0.5mm]0.140 [3.6mm]
L-65951-250-150-DAMLCDFigure 20.250 [6.3mm]0.230 [5.8mm]0.020 [0.5mm]0.150 [3.8mm]
L-65951-250-160-DAMLCDFigure 20.250 [6.3mm]0.230 [5.8mm]0.020 [0.5mm]0.160 [4.1mm]
L-65951-250-170-DAMLCDFigure 20.250 [6.3mm]0.230 [5.8mm]0.020 [0.5mm]0.170 [4.3mm]
L-65951-250-180-DAMLCDFigure 20.250 [6.3mm]0.230 [5.8mm]0.020 [0.5mm]0.180 [4.6mm]
L-65951-250-190-DAMLCDFigure 20.250 [6.3mm]0.230 [5.8mm]0.020 [0.5mm]0.190 [4.8mm]
L-65951-250-200-DAMLCDFigure 20.250 [6.3mm]0.230 [5.8mm]0.020 [0.5mm]0.200 [5.1mm]
L-65951-280-120-DAMLCDFigure 20.280 [7.1mm]0.260 [6.6mm]0.020 [0.5mm]0.120 [3.0mm]
L-65951-280-130-DAMLCDFigure 20.280 [7.1mm]0.260 [6.6mm]0.020 [0.5mm]0.130 [3.3mm]
L-65951-280-140-DAMLCDFigure 20.280 [7.1mm]0.260 [6.6mm]0.020 [0.5mm]0.140 [3.6mm]
L-65951-280-150-DAMLCDFigure 20.280 [7.1mm]0.260 [6.6mm]0.020 [0.5mm]0.150 [3.8mm]
L-65951-280-160-DAMLCDFigure 20.280 [7.1mm]0.260 [6.6mm]0.020 [0.5mm]0.160 [4.1mm]
L-65951-280-170-DAMLCDFigure 20.280 [7.1mm]0.260 [6.6mm]0.020 [0.5mm]0.170 [4.3mm]
L-65951-280-180-DAMLCDFigure 20.280 [7.1mm]0.260 [6.6mm]0.020 [0.5mm]0.180 [4.6mm]
L-65951-280-190-DAMLCDFigure 20.280 [7.1mm]0.260 [6.6mm]0.020 [0.5mm]0.190 [4.8mm]
L-65951-280-200-DAMLCDFigure 20.280 [7.1mm]0.260 [6.6mm]0.020 [0.5mm]0.200 [5.1mm]
L-65401-185-120-DYellow Class AFigure 20.185 [4.7mm]0.105 [2.7mm]0.040 [1.1mm]0.120 [3.0mm]
L-65401-185-130-DYellow Class AFigure 20.185 [4.7mm]0.105 [2.7mm]0.040 [1.1mm]0.130 [3.3mm]
L-65401-185-140-DYellow Class AFigure 20.185 [4.7mm]0.105 [2.7mm]0.040 [1.1mm]0.140 [3.6mm]
L-65401-185-150-DYellow Class AFigure 20.185 [4.7mm]0.105 [2.7mm]0.040 [1.1mm]0.150 [3.8mm]
L-65401-185-160-DYellow Class AFigure 20.185 [4.7mm]0.105 [2.7mm]0.040 [1.1mm]0.160 [4.1mm]
L-65401-185-170-DYellow Class AFigure 20.185 [4.7mm]0.105 [2.7mm]0.040 [1.1mm]0.170 [4.3mm]
L-65401-185-180-DYellow Class AFigure 20.185 [4.7mm]0.105 [2.7mm]0.040 [1.1mm]0.180 [4.6mm]
L-65401-185-190-DYellow Class AFigure 20.185 [4.7mm]0.105 [2.7mm]0.040 [1.1mm]0.190 [4.8mm]
L-65401-185-200-DYellow Class AFigure 20.185 [4.7mm]0.105 [2.7mm]0.040 [1.1mm]0.200 [5.1mm]
L-65401-210-120-DYellow Class AFigure 20.210 [5.3mm]0.130 [3.3mm]0.040 [1.1mm]0.120 [3.0mm]
L-65401-210-130-DYellow Class AFigure 20.210 [5.3mm]0.130 [3.3mm]0.040 [1.1mm]0.130 [3.3mm]
L-65401-210-140-DYellow Class AFigure 20.210 [5.3mm]0.130 [3.3mm]0.040 [1.1mm]0.140 [3.6mm]
L-65401-210-150-DYellow Class AFigure 20.210 [5.3mm]0.130 [3.3mm]0.040 [1.1mm]0.150 [3.8mm]
L-65401-210-160-DYellow Class AFigure 20.210 [5.3mm]0.130 [3.3mm]0.040 [1.1mm]0.160 [4.1mm]
L-65401-210-170-DYellow Class AFigure 20.210 [5.3mm]0.130 [3.3mm]0.040 [1.1mm]0.170 [4.3mm]
L-65401-210-180-DYellow Class AFigure 20.210 [5.3mm]0.130 [3.3mm]0.040 [1.1mm]0.180 [4.6mm]
L-65401-210-190-DYellow Class AFigure 20.210 [5.3mm]0.130 [3.3mm]0.040 [1.1mm]0.190 [4.8mm]
L-65401-210-200-DYellow Class AFigure 20.210 [5.3mm]0.130 [3.3mm]0.040 [1.1mm]0.200 [5.1mm]
L-65401-240-120-DYellow Class AFigure 20.240 [6.1mm]0.160 [4.1mm]0.040 [1.1mm]0.120 [3.0mm]
L-65401-240-130-DYellow Class AFigure 20.240 [6.1mm]0.160 [4.1mm]0.040 [1.1mm]0.130 [3.3mm]
L-65401-240-140-DYellow Class AFigure 20.240 [6.1mm]0.160 [4.1mm]0.040 [1.1mm]0.140 [3.6mm]
L-65401-240-150-DYellow Class AFigure 20.240 [6.1mm]0.160 [4.1mm]0.040 [1.1mm]0.150 [3.8mm]
L-65401-240-160-DYellow Class AFigure 20.240 [6.1mm]0.160 [4.1mm]0.040 [1.1mm]0.160 [4.1mm]
L-65401-240-170-DYellow Class AFigure 20.240 [6.1mm]0.160 [4.1mm]0.040 [1.1mm]0.170 [4.3mm]
L-65401-240-180-DYellow Class AFigure 20.240 [6.1mm]0.160 [4.1mm]0.040 [1.1mm]0.180 [4.6mm]
L-65401-240-190-DYellow Class AFigure 20.240 [6.1mm]0.160 [4.1mm]0.040 [1.1mm]0.190 [4.8mm]
L-65401-240-200-DYellow Class AFigure 20.240 [6.1mm]0.160 [4.1mm]0.040 [1.1mm]0.200 [5.1mm]
L-65401-250-120-DYellow Class AFigure 20.250 [6.3mm]0.170 [4.3mm]0.040 [1.1mm]0.120 [3.0mm]
L-65401-250-130-DYellow Class AFigure 20.250 [6.3mm]0.170 [4.3mm]0.040 [1.1mm]0.130 [3.3mm]
L-65401-250-140-DYellow Class AFigure 20.250 [6.3mm]0.170 [4.3mm]0.040 [1.1mm]0.140 [3.6mm]
L-65401-250-150-DYellow Class AFigure 20.250 [6.3mm]0.170 [4.3mm]0.040 [1.1mm]0.150 [3.8mm]
L-65401-250-160-DYellow Class AFigure 20.250 [6.3mm]0.170 [4.3mm]0.040 [1.1mm]0.160 [4.1mm]
L-65401-250-170-DYellow Class AFigure 20.250 [6.3mm]0.170 [4.3mm]0.040 [1.1mm]0.170 [4.3mm]
L-65401-250-180-DYellow Class AFigure 20.250 [6.3mm]0.170 [4.3mm]0.040 [1.1mm]0.180 [4.6mm]
L-65401-250-190-DYellow Class AFigure 20.250 [6.3mm]0.170 [4.3mm]0.040 [1.1mm]0.190 [4.8mm]
L-65401-250-200-DYellow Class AFigure 20.250 [6.3mm]0.170 [4.3mm]0.040 [1.1mm]0.200 [5.1mm]
L-65401-280-120-DYellow Class AFigure 20.280 [7.1mm]0.200 [5.1mm]0.040 [1.1mm]0.120 [3.0mm]
L-65401-280-130-DYellow Class AFigure 20.280 [7.1mm]0.200 [5.1mm]0.040 [1.1mm]0.130 [3.3mm]
L-65401-280-140-DYellow Class AFigure 20.280 [7.1mm]0.200 [5.1mm]0.040 [1.1mm]0.140 [3.6mm]
L-65401-280-150-DYellow Class AFigure 20.280 [7.1mm]0.200 [5.1mm]0.040 [1.1mm]0.150 [3.8mm]
L-65401-280-160-DYellow Class AFigure 20.280 [7.1mm]0.200 [5.1mm]0.040 [1.1mm]0.160 [4.1mm]
L-65401-280-170-DYellow Class AFigure 20.280 [7.1mm]0.200 [5.1mm]0.040 [1.1mm]0.170 [4.3mm]
L-65401-280-180-DYellow Class AFigure 20.280 [7.1mm]0.200 [5.1mm]0.040 [1.1mm]0.180 [4.6mm]
L-65401-280-190-DYellow Class AFigure 20.280 [7.1mm]0.200 [5.1mm]0.040 [1.1mm]0.190 [4.8mm]
L-65401-280-200-DYellow Class AFigure 20.280 [7.1mm]0.200 [5.1mm]0.040 [1.1mm]0.200 [5.1mm]
L-65402-185-120-DYellow Class BFigure 20.185 [4.7mm]0.105 [2.7mm]0.040 [1.1mm]0.120 [3.0mm]
L-65402-185-130-DYellow Class BFigure 20.185 [4.7mm]0.105 [2.7mm]0.040 [1.1mm]0.130 [3.3mm]
L-65402-185-140-DYellow Class BFigure 20.185 [4.7mm]0.105 [2.7mm]0.040 [1.1mm]0.140 [3.6mm]
L-65402-185-150-DYellow Class BFigure 20.185 [4.7mm]0.105 [2.7mm]0.040 [1.1mm]0.150 [3.8mm]
L-65402-185-160-DYellow Class BFigure 20.185 [4.7mm]0.105 [2.7mm]0.040 [1.1mm]0.160 [4.1mm]
L-65402-185-170-DYellow Class BFigure 20.185 [4.7mm]0.105 [2.7mm]0.040 [1.1mm]0.170 [4.3mm]
L-65402-185-180-DYellow Class BFigure 20.185 [4.7mm]0.105 [2.7mm]0.040 [1.1mm]0.180 [4.6mm]
L-65402-185-190-DYellow Class BFigure 20.185 [4.7mm]0.105 [2.7mm]0.040 [1.1mm]0.190 [4.8mm]
L-65402-185-200-DYellow Class BFigure 20.185 [4.7mm]0.105 [2.7mm]0.040 [1.1mm]0.200 [5.1mm]
L-65402-210-120-DYellow Class BFigure 20.210 [5.3mm]0.130 [3.3mm]0.040 [1.1mm]0.120 [3.0mm]
L-65402-210-130-DYellow Class BFigure 20.210 [5.3mm]0.130 [3.3mm]0.040 [1.1mm]0.130 [3.3mm]
L-65402-210-140-DYellow Class BFigure 20.210 [5.3mm]0.130 [3.3mm]0.040 [1.1mm]0.140 [3.6mm]
L-65402-210-150-DYellow Class BFigure 20.210 [5.3mm]0.130 [3.3mm]0.040 [1.1mm]0.150 [3.8mm]
L-65402-210-160-DYellow Class BFigure 20.210 [5.3mm]0.130 [3.3mm]0.040 [1.1mm]0.160 [4.1mm]
L-65402-210-170-DYellow Class BFigure 20.210 [5.3mm]0.130 [3.3mm]0.040 [1.1mm]0.170 [4.3mm]
L-65402-210-180-DYellow Class BFigure 20.210 [5.3mm]0.130 [3.3mm]0.040 [1.1mm]0.180 [4.6mm]
L-65402-210-190-DYellow Class BFigure 20.210 [5.3mm]0.130 [3.3mm]0.040 [1.1mm]0.190 [4.8mm]
L-65402-210-200-DYellow Class BFigure 20.210 [5.3mm]0.130 [3.3mm]0.040 [1.1mm]0.200 [5.1mm]
L-65402-240-120-DYellow Class BFigure 20.240 [6.1mm]0.160 [4.1mm]0.040 [1.1mm]0.120 [3.0mm]
L-65402-240-130-DYellow Class BFigure 20.240 [6.1mm]0.160 [4.1mm]0.040 [1.1mm]0.130 [3.3mm]
L-65402-240-140-DYellow Class BFigure 20.240 [6.1mm]0.160 [4.1mm]0.040 [1.1mm]0.140 [3.6mm]
L-65402-240-150-DYellow Class BFigure 20.240 [6.1mm]0.160 [4.1mm]0.040 [1.1mm]0.150 [3.8mm]
L-65402-240-160-DYellow Class BFigure 20.240 [6.1mm]0.160 [4.1mm]0.040 [1.1mm]0.160 [4.1mm]
L-65402-240-170-DYellow Class BFigure 20.240 [6.1mm]0.160 [4.1mm]0.040 [1.1mm]0.170 [4.3mm]
L-65402-240-180-DYellow Class BFigure 20.240 [6.1mm]0.160 [4.1mm]0.040 [1.1mm]0.180 [4.6mm]
L-65402-240-190-DYellow Class BFigure 20.240 [6.1mm]0.160 [4.1mm]0.040 [1.1mm]0.190 [4.8mm]
L-65402-240-200-DYellow Class BFigure 20.240 [6.1mm]0.160 [4.1mm]0.040 [1.1mm]0.200 [5.1mm]
L-65402-250-120-DYellow Class BFigure 20.250 [6.3mm]0.170 [4.3mm]0.040 [1.1mm]0.120 [3.0mm]
L-65402-250-130-DYellow Class BFigure 20.250 [6.3mm]0.170 [4.3mm]0.040 [1.1mm]0.130 [3.3mm]
L-65402-250-140-DYellow Class BFigure 20.250 [6.3mm]0.170 [4.3mm]0.040 [1.1mm]0.140 [3.6mm]
L-65402-250-150-DYellow Class BFigure 20.250 [6.3mm]0.170 [4.3mm]0.040 [1.1mm]0.150 [3.8mm]
L-65402-250-160-DYellow Class BFigure 20.250 [6.3mm]0.170 [4.3mm]0.040 [1.1mm]0.160 [4.1mm]
L-65402-250-170-DYellow Class BFigure 20.250 [6.3mm]0.170 [4.3mm]0.040 [1.1mm]0.170 [4.3mm]
L-65402-250-180-DYellow Class BFigure 20.250 [6.3mm]0.170 [4.3mm]0.040 [1.1mm]0.180 [4.6mm]
L-65402-250-190-DYellow Class BFigure 20.250 [6.3mm]0.170 [4.3mm]0.040 [1.1mm]0.190 [4.8mm]
L-65402-250-200-DYellow Class BFigure 20.250 [6.3mm]0.170 [4.3mm]0.040 [1.1mm]0.200 [5.1mm]
L-65402-280-120-DYellow Class BFigure 20.280 [7.1mm]0.200 [5.1mm]0.040 [1.1mm]0.120 [3.0mm]
L-65402-280-130-DYellow Class BFigure 20.280 [7.1mm]0.200 [5.1mm]0.040 [1.1mm]0.130 [3.3mm]
L-65402-280-140-DYellow Class BFigure 20.280 [7.1mm]0.200 [5.1mm]0.040 [1.1mm]0.140 [3.6mm]
L-65402-280-150-DYellow Class BFigure 20.280 [7.1mm]0.200 [5.1mm]0.040 [1.1mm]0.150 [3.8mm]
L-65402-280-160-DYellow Class BFigure 20.280 [7.1mm]0.200 [5.1mm]0.040 [1.1mm]0.160 [4.1mm]
L-65402-280-170-DYellow Class BFigure 20.280 [7.1mm]0.200 [5.1mm]0.040 [1.1mm]0.170 [4.3mm]
L-65402-280-180-DYellow Class BFigure 20.280 [7.1mm]0.200 [5.1mm]0.040 [1.1mm]0.180 [4.6mm]
L-65402-280-190-DYellow Class BFigure 20.280 [7.1mm]0.200 [5.1mm]0.040 [1.1mm]0.190 [4.8mm]
L-65402-280-200-DYellow Class BFigure 20.280 [7.1mm]0.200 [5.1mm]0.040 [1.1mm]0.200 [5.1mm]
L-65403-185-120-DRed Class BFigure 20.185 [4.7mm]0.105 [2.7mm]0.020 [0.5mm]0.120 [3.0mm]
L-65403-185-130-DRed Class BFigure 20.185 [4.7mm]0.105 [2.7mm]0.020 [0.5mm]0.130 [3.3mm]
L-65403-185-140-DRed Class BFigure 20.185 [4.7mm]0.105 [2.7mm]0.020 [0.5mm]0.140 [3.6mm]
L-65403-185-150-DRed Class BFigure 20.185 [4.7mm]0.105 [2.7mm]0.020 [0.5mm]0.150 [3.8mm]
L-65403-185-160-DRed Class BFigure 20.185 [4.7mm]0.105 [2.7mm]0.020 [0.5mm]0.160 [4.1mm]
L-65403-185-170-DRed Class BFigure 20.185 [4.7mm]0.105 [2.7mm]0.020 [0.5mm]0.170 [4.3mm]
L-65403-185-180-DRed Class BFigure 20.185 [4.7mm]0.105 [2.7mm]0.020 [0.5mm]0.180 [4.6mm]
L-65403-185-190-DRed Class BFigure 20.185 [4.7mm]0.105 [2.7mm]0.020 [0.5mm]0.190 [4.8mm]
L-65403-185-200-DRed Class BFigure 20.185 [4.7mm]0.105 [2.7mm]0.020 [0.5mm]0.200 [5.1mm]
L-65403-210-120-DRed Class BFigure 20.210 [5.3mm]0.130 [3.3mm]0.020 [0.5mm]0.120 [3.0mm]
L-65403-210-130-DRed Class BFigure 20.210 [5.3mm]0.130 [3.3mm]0.020 [0.5mm]0.130 [3.3mm]
L-65403-210-140-DRed Class BFigure 20.210 [5.3mm]0.130 [3.3mm]0.020 [0.5mm]0.140 [3.6mm]
L-65403-210-150-DRed Class BFigure 20.210 [5.3mm]0.130 [3.3mm]0.020 [0.5mm]0.150 [3.8mm]
L-65403-210-160-DRed Class BFigure 20.210 [5.3mm]0.130 [3.3mm]0.020 [0.5mm]0.160 [4.1mm]
L-65403-210-170-DRed Class BFigure 20.210 [5.3mm]0.130 [3.3mm]0.020 [0.5mm]0.170 [4.3mm]
L-65403-210-180-DRed Class BFigure 20.210 [5.3mm]0.130 [3.3mm]0.020 [0.5mm]0.180 [4.6mm]
L-65403-210-190-DRed Class BFigure 20.210 [5.3mm]0.130 [3.3mm]0.020 [0.5mm]0.190 [4.8mm]
L-65403-210-200-DRed Class BFigure 20.210 [5.3mm]0.130 [3.3mm]0.020 [0.5mm]0.200 [5.1mm]
L-65403-240-120-DRed Class BFigure 20.240 [6.1mm]0.160 [4.1mm]0.020 [0.5mm]0.120 [3.0mm]
L-65403-240-130-DRed Class BFigure 20.240 [6.1mm]0.160 [4.1mm]0.020 [0.5mm]0.130 [3.3mm]
L-65403-240-140-DRed Class BFigure 20.240 [6.1mm]0.160 [4.1mm]0.020 [0.5mm]0.140 [3.6mm]
L-65403-240-150-DRed Class BFigure 20.240 [6.1mm]0.160 [4.1mm]0.020 [0.5mm]0.150 [3.8mm]
L-65403-240-160-DRed Class BFigure 20.240 [6.1mm]0.160 [4.1mm]0.020 [0.5mm]0.160 [4.1mm]
L-65403-240-170-DRed Class BFigure 20.240 [6.1mm]0.160 [4.1mm]0.020 [0.5mm]0.170 [4.3mm]
L-65403-240-180-DRed Class BFigure 20.240 [6.1mm]0.160 [4.1mm]0.020 [0.5mm]0.180 [4.6mm]
L-65403-240-190-DRed Class BFigure 20.240 [6.1mm]0.160 [4.1mm]0.020 [0.5mm]0.190 [4.8mm]
L-65403-240-200-DRed Class BFigure 20.240 [6.1mm]0.160 [4.1mm]0.020 [0.5mm]0.200 [5.1mm]
L-65403-250-120-DRed Class BFigure 20.250 [6.3mm]0.170 [4.3mm]0.020 [0.5mm]0.120 [3.0mm]
L-65403-250-130-DRed Class BFigure 20.250 [6.3mm]0.170 [4.3mm]0.020 [0.5mm]0.130 [3.3mm]
L-65403-250-140-DRed Class BFigure 20.250 [6.3mm]0.170 [4.3mm]0.020 [0.5mm]0.140 [3.6mm]
L-65403-250-150-DRed Class BFigure 20.250 [6.3mm]0.170 [4.3mm]0.020 [0.5mm]0.150 [3.8mm]
L-65403-250-160-DRed Class BFigure 20.250 [6.3mm]0.170 [4.3mm]0.020 [0.5mm]0.160 [4.1mm]
L-65403-250-170-DRed Class BFigure 20.250 [6.3mm]0.170 [4.3mm]0.020 [0.5mm]0.170 [4.3mm]
L-65403-250-180-DRed Class BFigure 20.250 [6.3mm]0.170 [4.3mm]0.020 [0.5mm]0.180 [4.6mm]
L-65403-250-190-DRed Class BFigure 20.250 [6.3mm]0.170 [4.3mm]0.020 [0.5mm]0.190 [4.8mm]
L-65403-250-200-DRed Class BFigure 20.250 [6.3mm]0.170 [4.3mm]0.020 [0.5mm]0.200 [5.1mm]
L-65403-280-120-DRed Class BFigure 20.280 [7.1mm]0.200 [5.1mm]0.020 [0.5mm]0.120 [3.0mm]
L-65403-280-130-DRed Class BFigure 20.280 [7.1mm]0.200 [5.1mm]0.020 [0.5mm]0.130 [3.3mm]
L-65403-280-140-DRed Class BFigure 20.280 [7.1mm]0.200 [5.1mm]0.020 [0.5mm]0.140 [3.6mm]
L-65403-280-150-DRed Class BFigure 20.280 [7.1mm]0.200 [5.1mm]0.020 [0.5mm]0.150 [3.8mm]
L-65403-280-160-DRed Class BFigure 20.280 [7.1mm]0.200 [5.1mm]0.020 [0.5mm]0.160 [4.1mm]
L-65403-280-170-DRed Class BFigure 20.280 [7.1mm]0.200 [5.1mm]0.020 [0.5mm]0.170 [4.3mm]
L-65403-280-180-DRed Class BFigure 20.280 [7.1mm]0.200 [5.1mm]0.020 [0.5mm]0.180 [4.6mm]
L-65403-280-190-DRed Class BFigure 20.280 [7.1mm]0.200 [5.1mm]0.020 [0.5mm]0.190 [4.8mm]
L-65403-280-200-DRed Class BFigure 20.280 [7.1mm]0.200 [5.1mm]0.020 [0.5mm]0.200 [5.1mm]
L-65196-185-120-HSGreen AFigure 30.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.120 [3.0mm]
L-65196-185-130-HSGreen AFigure 30.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.130 [3.3mm]
L-65196-185-140-HSGreen AFigure 30.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.140 [3.6mm]
L-65196-185-150-HSGreen AFigure 30.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.150 [3.8mm]
L-65196-185-160-HSGreen AFigure 30.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.160 [4.1mm]
L-65196-185-170-HSGreen AFigure 30.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.170 [4.3mm]
L-65196-185-180-HSGreen AFigure 30.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.180 [4.6mm]
L-65196-185-190-HSGreen AFigure 30.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.190 [4.8mm]
L-65196-185-200-HSGreen AFigure 30.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.200 [5.1mm]
L-65196-210-120-HSGreen AFigure 30.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.120 [3.0mm]
L-65196-210-130-HSGreen AFigure 30.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.130 [3.3mm]
L-65196-210-140-HSGreen AFigure 30.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.140 [3.6mm]
L-65196-210-150-HSGreen AFigure 30.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.150 [3.8mm]
L-65196-210-160-HSGreen AFigure 30.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.160 [4.1mm]
L-65196-210-170-HSGreen AFigure 30.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.170 [4.3mm]
L-65196-210-180-HSGreen AFigure 30.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.180 [4.6mm]
L-65196-210-190-HSGreen AFigure 30.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.190 [4.8mm]
L-65196-210-200-HSGreen AFigure 30.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.200 [5.1mm]
L-65196-240-120-HSGreen AFigure 30.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.120 [3.0mm]
L-65196-240-130-HSGreen AFigure 30.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.130 [3.3mm]
L-65196-240-140-HSGreen AFigure 30.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.140 [3.6mm]
L-65196-240-150-HSGreen AFigure 30.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.150 [3.8mm]
L-65196-240-160-HSGreen AFigure 30.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.160 [4.1mm]
L-65196-240-170-HSGreen AFigure 30.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.170 [4.3mm]
L-65196-240-180-HSGreen AFigure 30.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.180 [4.6mm]
L-65196-240-190-HSGreen AFigure 30.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.190 [4.8mm]
L-65196-240-200-HSGreen AFigure 30.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.200 [5.1mm]
L-65196-250-120-HSGreen AFigure 30.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.120 [3.0mm]
L-65196-250-130-HSGreen AFigure 30.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.130 [3.3mm]
L-65196-250-140-HSGreen AFigure 30.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.140 [3.6mm]
L-65196-250-150-HSGreen AFigure 30.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.150 [3.8mm]
L-65196-250-160-HSGreen AFigure 30.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.160 [4.1mm]
L-65196-250-170-HSGreen AFigure 30.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.170 [4.3mm]
L-65196-250-180-HSGreen AFigure 30.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.180 [4.6mm]
L-65196-250-190-HSGreen AFigure 30.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.190 [4.8mm]
L-65196-250-200-HSGreen AFigure 30.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.200 [5.1mm]
L-65196-280-120-HSGreen AFigure 30.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.120 [3.0mm]
L-65196-280-130-HSGreen AFigure 30.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.130 [3.3mm]
L-65196-280-140-HSGreen AFigure 30.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.140 [3.6mm]
L-65196-280-150-HSGreen AFigure 30.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.150 [3.8mm]
L-65196-280-160-HSGreen AFigure 30.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.160 [4.1mm]
L-65196-280-170-HSGreen AFigure 30.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.170 [4.3mm]
L-65196-280-180-HSGreen AFigure 30.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.180 [4.6mm]
L-65196-280-190-HSGreen AFigure 30.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.190 [4.8mm]
L-65196-280-200-HSGreen AFigure 30.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.200 [5.1mm]
L-65330-185-120-HSGreen AFigure 30.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.120 [3.0mm]
L-65330-185-130-HSGreen AFigure 30.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.130 [3.3mm]
L-65330-185-140-HSGreen AFigure 30.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.140 [3.6mm]
L-65330-185-150-HSGreen AFigure 30.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.150 [3.8mm]
L-65330-185-160-HSGreen AFigure 30.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.160 [4.1mm]
L-65330-185-170-HSGreen AFigure 30.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.170 [4.3mm]
L-65330-185-180-HSGreen AFigure 30.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.180 [4.6mm]
L-65330-185-190-HSGreen AFigure 30.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.190 [4.8mm]
L-65330-185-200-HSGreen AFigure 30.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.200 [5.1mm]
L-65330-210-120-HSGreen AFigure 30.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.120 [3.0mm]
L-65330-210-130-HSGreen AFigure 30.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.130 [3.3mm]
L-65330-210-140-HSGreen AFigure 30.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.140 [3.6mm]
L-65330-210-150-HSGreen AFigure 30.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.150 [3.8mm]
L-65330-210-160-HSGreen AFigure 30.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.160 [4.1mm]
L-65330-210-170-HSGreen AFigure 30.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.170 [4.3mm]
L-65330-210-180-HSGreen AFigure 30.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.180 [4.6mm]
L-65330-210-190-HSGreen AFigure 30.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.190 [4.8mm]
L-65330-210-200-HSGreen AFigure 30.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.200 [5.1mm]
L-65330-240-120-HSGreen AFigure 30.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.120 [3.0mm]
L-65330-240-130-HSGreen AFigure 30.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.130 [3.3mm]
L-65330-240-140-HSGreen AFigure 30.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.140 [3.6mm]
L-65330-240-150-HSGreen AFigure 30.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.150 [3.8mm]
L-65330-240-160-HSGreen AFigure 30.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.160 [4.1mm]
L-65330-240-170-HSGreen AFigure 30.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.170 [4.3mm]
L-65330-240-180-HSGreen AFigure 30.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.180 [4.6mm]
L-65330-240-190-HSGreen AFigure 30.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.190 [4.8mm]
L-65330-240-200-HSGreen AFigure 30.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.200 [5.1mm]
L-65330-250-120-HSGreen AFigure 30.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.120 [3.0mm]
L-65330-250-130-HSGreen AFigure 30.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.130 [3.3mm]
L-65330-250-140-HSGreen AFigure 30.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.140 [3.6mm]
L-65330-250-150-HSGreen AFigure 30.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.150 [3.8mm]
L-65330-250-160-HSGreen AFigure 30.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.160 [4.1mm]
L-65330-250-170-HSGreen AFigure 30.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.170 [4.3mm]
L-65330-250-180-HSGreen AFigure 30.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.180 [4.6mm]
L-65330-250-190-HSGreen AFigure 30.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.190 [4.8mm]
L-65330-250-200-HSGreen AFigure 30.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.200 [5.1mm]
L-65330-280-120-HSGreen AFigure 30.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.120 [3.0mm]
L-65330-280-130-HSGreen AFigure 30.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.130 [3.3mm]
L-65330-280-140-HSGreen AFigure 30.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.140 [3.6mm]
L-65330-280-150-HSGreen AFigure 30.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.150 [3.8mm]
L-65330-280-160-HSGreen AFigure 30.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.160 [4.1mm]
L-65330-280-170-HSGreen AFigure 30.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.170 [4.3mm]
L-65330-280-180-HSGreen AFigure 30.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.180 [4.6mm]
L-65330-280-190-HSGreen AFigure 30.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.190 [4.8mm]
L-65330-280-200-HSGreen AFigure 30.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.200 [5.1mm]
L-65197-185-120-HSGreen BFigure 30.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.120 [3.0mm]
L-65197-185-130-HSGreen BFigure 30.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.130 [3.3mm]
L-65197-185-140-HSGreen BFigure 30.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.140 [3.6mm]
L-65197-185-150-HSGreen BFigure 30.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.150 [3.8mm]
L-65197-185-160-HSGreen BFigure 30.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.160 [4.1mm]
L-65197-185-170-HSGreen BFigure 30.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.170 [4.3mm]
L-65197-185-180-HSGreen BFigure 30.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.180 [4.6mm]
L-65197-185-190-HSGreen BFigure 30.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.190 [4.8mm]
L-65197-185-200-HSGreen BFigure 30.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.200 [5.1mm]
L-65197-210-120-HSGreen BFigure 30.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.120 [3.0mm]
L-65197-210-130-HSGreen BFigure 30.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.130 [3.3mm]
L-65197-210-140-HSGreen BFigure 30.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.140 [3.6mm]
L-65197-210-150-HSGreen BFigure 30.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.150 [3.8mm]
L-65197-210-160-HSGreen BFigure 30.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.160 [4.1mm]
L-65197-210-170-HSGreen BFigure 30.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.170 [4.3mm]
L-65197-210-180-HSGreen BFigure 30.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.180 [4.6mm]
L-65197-210-190-HSGreen BFigure 30.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.190 [4.8mm]
L-65197-210-200-HSGreen BFigure 30.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.200 [5.1mm]
L-65197-240-120-HSGreen BFigure 30.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.120 [3.0mm]
L-65197-240-130-HSGreen BFigure 30.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.130 [3.3mm]
L-65197-240-140-HSGreen BFigure 30.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.140 [3.6mm]
L-65197-240-150-HSGreen BFigure 30.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.150 [3.8mm]
L-65197-240-160-HSGreen BFigure 30.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.160 [4.1mm]
L-65197-240-170-HSGreen BFigure 30.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.170 [4.3mm]
L-65197-240-180-HSGreen BFigure 30.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.180 [4.6mm]
L-65197-240-190-HSGreen BFigure 30.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.190 [4.8mm]
L-65197-240-200-HSGreen BFigure 30.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.200 [5.1mm]
L-65197-250-120-HSGreen BFigure 30.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.120 [3.0mm]
L-65197-250-130-HSGreen BFigure 30.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.130 [3.3mm]
L-65197-250-140-HSGreen BFigure 30.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.140 [3.6mm]
L-65197-250-150-HSGreen BFigure 30.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.150 [3.8mm]
L-65197-250-160-HSGreen BFigure 30.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.160 [4.1mm]
L-65197-250-170-HSGreen BFigure 30.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.170 [4.3mm]
L-65197-250-180-HSGreen BFigure 30.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.180 [4.6mm]
L-65197-250-190-HSGreen BFigure 30.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.190 [4.8mm]
L-65197-250-200-HSGreen BFigure 30.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.200 [5.1mm]
L-65197-280-120-HSGreen BFigure 30.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.120 [3.0mm]
L-65197-280-130-HSGreen BFigure 30.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.130 [3.3mm]
L-65197-280-140-HSGreen BFigure 30.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.140 [3.6mm]
L-65197-280-150-HSGreen BFigure 30.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.150 [3.8mm]
L-65197-280-160-HSGreen BFigure 30.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.160 [4.1mm]
L-65197-280-170-HSGreen BFigure 30.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.170 [4.3mm]
L-65197-280-180-HSGreen BFigure 30.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.180 [4.6mm]
L-65197-280-190-HSGreen BFigure 30.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.190 [4.8mm]
L-65197-280-200-HSGreen BFigure 30.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.200 [5.1mm]
L-65250-185-120-HSGreen BFigure 30.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.120 [3.0mm]
L-65250-185-130-HSGreen BFigure 30.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.130 [3.3mm]
L-65250-185-140-HSGreen BFigure 30.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.140 [3.6mm]
L-65250-185-150-HSGreen BFigure 30.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.150 [3.8mm]
L-65250-185-160-HSGreen BFigure 30.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.160 [4.1mm]
L-65250-185-170-HSGreen BFigure 30.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.170 [4.3mm]
L-65250-185-180-HSGreen BFigure 30.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.180 [4.6mm]
L-65250-185-190-HSGreen BFigure 30.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.190 [4.8mm]
L-65250-185-200-HSGreen BFigure 30.185 [4.7mm]0.125 [3.1mm]0.030 [0.8mm]0.200 [5.1mm]
L-65250-210-120-HSGreen BFigure 30.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.120 [3.0mm]
L-65250-210-130-HSGreen BFigure 30.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.130 [3.3mm]
L-65250-210-140-HSGreen BFigure 30.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.140 [3.6mm]
L-65250-210-150-HSGreen BFigure 30.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.150 [3.8mm]
L-65250-210-160-HSGreen BFigure 30.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.160 [4.1mm]
L-65250-210-170-HSGreen BFigure 30.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.170 [4.3mm]
L-65250-210-180-HSGreen BFigure 30.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.180 [4.6mm]
L-65250-210-190-HSGreen BFigure 30.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.190 [4.8mm]
L-65250-210-200-HSGreen BFigure 30.210 [5.3mm]0.150 [3.8mm]0.030 [0.8mm]0.200 [5.1mm]
L-65250-240-120-HSGreen BFigure 30.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.120 [3.0mm]
L-65250-240-130-HSGreen BFigure 30.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.130 [3.3mm]
L-65250-240-140-HSGreen BFigure 30.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.140 [3.6mm]
L-65250-240-150-HSGreen BFigure 30.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.150 [3.8mm]
L-65250-240-160-HSGreen BFigure 30.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.160 [4.1mm]
L-65250-240-170-HSGreen BFigure 30.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.170 [4.3mm]
L-65250-240-180-HSGreen BFigure 30.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.180 [4.6mm]
L-65250-240-190-HSGreen BFigure 30.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.190 [4.8mm]
L-65250-240-200-HSGreen BFigure 30.240 [6.1mm]0.180 [4.6mm]0.030 [0.8mm]0.200 [5.1mm]
L-65250-250-120-HSGreen BFigure 30.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.120 [3.0mm]
L-65250-250-130-HSGreen BFigure 30.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.130 [3.3mm]
L-65250-250-140-HSGreen BFigure 30.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.140 [3.6mm]
L-65250-250-150-HSGreen BFigure 30.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.150 [3.8mm]
L-65250-250-160-HSGreen BFigure 30.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.160 [4.1mm]
L-65250-250-170-HSGreen BFigure 30.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.170 [4.3mm]
L-65250-250-180-HSGreen BFigure 30.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.180 [4.6mm]
L-65250-250-190-HSGreen BFigure 30.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.190 [4.8mm]
L-65250-250-200-HSGreen BFigure 30.250 [6.3mm]0.190 [4.8mm]0.030 [0.8mm]0.200 [5.1mm]
L-65250-280-120-HSGreen BFigure 30.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.120 [3.0mm]
L-65250-280-130-HSGreen BFigure 30.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.130 [3.3mm]
L-65250-280-140-HSGreen BFigure 30.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.140 [3.6mm]
L-65250-280-150-HSGreen BFigure 30.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.150 [3.8mm]
L-65250-280-160-HSGreen BFigure 30.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.160 [4.1mm]
L-65250-280-170-HSGreen BFigure 30.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.170 [4.3mm]
L-65250-280-180-HSGreen BFigure 30.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.180 [4.6mm]
L-65250-280-190-HSGreen BFigure 30.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.190 [4.8mm]
L-65250-280-200-HSGreen BFigure 30.280 [7.1mm]0.220 [5.6mm]0.030 [0.8mm]0.200 [5.1mm]
L-65648-185-120-HSWHITEFigure 30.185 [4.7mm]0.105 [2.7mm]0.040 [1.1mm]0.120 [3.0mm]
L-65648-185-130-HSWHITEFigure 30.185 [4.7mm]0.105 [2.7mm]0.040 [1.1mm]0.130 [3.3mm]
L-65648-185-140-HSWHITEFigure 30.185 [4.7mm]0.105 [2.7mm]0.040 [1.1mm]0.140 [3.6mm]
L-65648-185-150-HSWHITEFigure 30.185 [4.7mm]0.105 [2.7mm]0.040 [1.1mm]0.150 [3.8mm]
L-65648-185-160-HSWHITEFigure 30.185 [4.7mm]0.105 [2.7mm]0.040 [1.1mm]0.160 [4.1mm]
L-65648-185-170-HSWHITEFigure 30.185 [4.7mm]0.105 [2.7mm]0.040 [1.1mm]0.170 [4.3mm]
L-65648-185-180-HSWHITEFigure 30.185 [4.7mm]0.105 [2.7mm]0.040 [1.1mm]0.180 [4.6mm]
L-65648-185-190-HSWHITEFigure 30.185 [4.7mm]0.105 [2.7mm]0.040 [1.1mm]0.190 [4.8mm]
L-65648-185-200-HSWHITEFigure 30.185 [4.7mm]0.105 [2.7mm]0.040 [1.1mm]0.200 [5.1mm]
L-65648-210-120-HSWHITEFigure 30.210 [5.3mm]0.130 [3.3mm]0.040 [1.1mm]0.120 [3.0mm]
L-65648-210-130-HSWHITEFigure 30.210 [5.3mm]0.130 [3.3mm]0.040 [1.1mm]0.130 [3.3mm]
L-65648-210-140-HSWHITEFigure 30.210 [5.3mm]0.130 [3.3mm]0.040 [1.1mm]0.140 [3.6mm]
L-65648-210-150-HSWHITEFigure 30.210 [5.3mm]0.130 [3.3mm]0.040 [1.1mm]0.150 [3.8mm]
L-65648-210-160-HSWHITEFigure 30.210 [5.3mm]0.130 [3.3mm]0.040 [1.1mm]0.160 [4.1mm]
L-65648-210-170-HSWHITEFigure 30.210 [5.3mm]0.130 [3.3mm]0.040 [1.1mm]0.170 [4.3mm]
L-65648-210-180-HSWHITEFigure 30.210 [5.3mm]0.130 [3.3mm]0.040 [1.1mm]0.180 [4.6mm]
L-65648-210-190-HSWHITEFigure 30.210 [5.3mm]0.130 [3.3mm]0.040 [1.1mm]0.190 [4.8mm]
L-65648-210-200-HSWHITEFigure 30.210 [5.3mm]0.130 [3.3mm]0.040 [1.1mm]0.200 [5.1mm]
L-65648-240-120-HSWHITEFigure 30.240 [6.1mm]0.160 [4.1mm]0.040 [1.1mm]0.120 [3.0mm]
L-65648-240-130-HSWHITEFigure 30.240 [6.1mm]0.160 [4.1mm]0.040 [1.1mm]0.130 [3.3mm]
L-65648-240-140-HSWHITEFigure 30.240 [6.1mm]0.160 [4.1mm]0.040 [1.1mm]0.140 [3.6mm]
L-65648-240-150-HSWHITEFigure 30.240 [6.1mm]0.160 [4.1mm]0.040 [1.1mm]0.150 [3.8mm]
L-65648-240-160-HSWHITEFigure 30.240 [6.1mm]0.160 [4.1mm]0.040 [1.1mm]0.160 [4.1mm]
L-65648-240-170-HSWHITEFigure 30.240 [6.1mm]0.160 [4.1mm]0.040 [1.1mm]0.170 [4.3mm]
L-65648-240-180-HSWHITEFigure 30.240 [6.1mm]0.160 [4.1mm]0.040 [1.1mm]0.180 [4.6mm]
L-65648-240-190-HSWHITEFigure 30.240 [6.1mm]0.160 [4.1mm]0.040 [1.1mm]0.190 [4.8mm]
L-65648-240-200-HSWHITEFigure 30.240 [6.1mm]0.160 [4.1mm]0.040 [1.1mm]0.200 [5.1mm]
L-65648-250-120-HSWHITEFigure 30.250 [6.3mm]0.170 [4.3mm]0.040 [1.1mm]0.120 [3.0mm]
L-65648-250-130-HSWHITEFigure 30.250 [6.3mm]0.170 [4.3mm]0.040 [1.1mm]0.130 [3.3mm]
L-65648-250-140-HSWHITEFigure 30.250 [6.3mm]0.170 [4.3mm]0.040 [1.1mm]0.140 [3.6mm]
L-65648-250-150-HSWHITEFigure 30.250 [6.3mm]0.170 [4.3mm]0.040 [1.1mm]0.150 [3.8mm]
L-65648-250-160-HSWHITEFigure 30.250 [6.3mm]0.170 [4.3mm]0.040 [1.1mm]0.160 [4.1mm]
L-65648-250-170-HSWHITEFigure 30.250 [6.3mm]0.170 [4.3mm]0.040 [1.1mm]0.170 [4.3mm]
L-65648-250-180-HSWHITEFigure 30.250 [6.3mm]0.170 [4.3mm]0.040 [1.1mm]0.180 [4.6mm]
L-65648-250-190-HSWHITEFigure 30.250 [6.3mm]0.170 [4.3mm]0.040 [1.1mm]0.190 [4.8mm]
L-65648-250-200-HSWHITEFigure 30.250 [6.3mm]0.170 [4.3mm]0.040 [1.1mm]0.200 [5.1mm]
L-65648-280-120-HSWHITEFigure 30.280 [7.1mm]0.200 [5.1mm]0.040 [1.1mm]0.120 [3.0mm]
L-65648-280-130-HSWHITEFigure 30.280 [7.1mm]0.200 [5.1mm]0.040 [1.1mm]0.130 [3.3mm]
L-65648-280-140-HSWHITEFigure 30.280 [7.1mm]0.200 [5.1mm]0.040 [1.1mm]0.140 [3.6mm]
L-65648-280-150-HSWHITEFigure 30.280 [7.1mm]0.200 [5.1mm]0.040 [1.1mm]0.150 [3.8mm]
L-65648-280-160-HSWHITEFigure 30.280 [7.1mm]0.200 [5.1mm]0.040 [1.1mm]0.160 [4.1mm]
L-65648-280-170-HSWHITEFigure 30.280 [7.1mm]0.200 [5.1mm]0.040 [1.1mm]0.170 [4.3mm]
L-65648-280-180-HSWHITEFigure 30.280 [7.1mm]0.200 [5.1mm]0.040 [1.1mm]0.180 [4.6mm]
L-65648-280-190-HSWHITEFigure 30.280 [7.1mm]0.200 [5.1mm]0.040 [1.1mm]0.190 [4.8mm]
L-65648-280-200-HSWHITEFigure 30.280 [7.1mm]0.200 [5.1mm]0.040 [1.1mm]0.200 [5.1mm]
L-65951-185-120-HSAMLCDFigure 30.185 [4.7mm]0.165 [4.2mm]0.020 [0.5mm]0.120 [3.0mm]
L-65951-185-130-HSAMLCDFigure 30.185 [4.7mm]0.165 [4.2mm]0.020 [0.5mm]0.130 [3.3mm]
L-65951-185-140-HSAMLCDFigure 30.185 [4.7mm]0.165 [4.2mm]0.020 [0.5mm]0.140 [3.6mm]
L-65951-185-150-HSAMLCDFigure 30.185 [4.7mm]0.165 [4.2mm]0.020 [0.5mm]0.150 [3.8mm]
L-65951-185-160-HSAMLCDFigure 30.185 [4.7mm]0.165 [4.2mm]0.020 [0.5mm]0.160 [4.1mm]
L-65951-185-170-HSAMLCDFigure 30.185 [4.7mm]0.165 [4.2mm]0.020 [0.5mm]0.170 [4.3mm]
L-65951-185-180-HSAMLCDFigure 30.185 [4.7mm]0.165 [4.2mm]0.020 [0.5mm]0.180 [4.6mm]
L-65951-185-190-HSAMLCDFigure 30.185 [4.7mm]0.165 [4.2mm]0.020 [0.5mm]0.190 [4.8mm]
L-65951-185-200-HSAMLCDFigure 30.185 [4.7mm]0.165 [4.2mm]0.020 [0.5mm]0.200 [5.1mm]
L-65951-210-120-HSAMLCDFigure 30.210 [5.3mm]0.170 [4.3mm]0.020 [0.5mm]0.120 [3.0mm]
L-65951-210-130-HSAMLCDFigure 30.210 [5.3mm]0.170 [4.3mm]0.020 [0.5mm]0.130 [3.3mm]
L-65951-210-140-HSAMLCDFigure 30.210 [5.3mm]0.170 [4.3mm]0.020 [0.5mm]0.140 [3.6mm]
L-65951-210-150-HSAMLCDFigure 30.210 [5.3mm]0.170 [4.3mm]0.020 [0.5mm]0.150 [3.8mm]
L-65951-210-160-HSAMLCDFigure 30.210 [5.3mm]0.170 [4.3mm]0.020 [0.5mm]0.160 [4.1mm]
L-65951-210-170-HSAMLCDFigure 30.210 [5.3mm]0.170 [4.3mm]0.020 [0.5mm]0.170 [4.3mm]
L-65951-210-180-HSAMLCDFigure 30.210 [5.3mm]0.170 [4.3mm]0.020 [0.5mm]0.180 [4.6mm]
L-65951-210-190-HSAMLCDFigure 30.210 [5.3mm]0.170 [4.3mm]0.020 [0.5mm]0.190 [4.8mm]
L-65951-210-200-HSAMLCDFigure 30.210 [5.3mm]0.170 [4.3mm]0.020 [0.5mm]0.200 [5.1mm]
L-65951-240-120-HSAMLCDFigure 30.240 [6.1mm]0.220 [5.6mm]0.020 [0.5mm]0.120 [3.0mm]
L-65951-240-130-HSAMLCDFigure 30.240 [6.1mm]0.220 [5.6mm]0.020 [0.5mm]0.130 [3.3mm]
L-65951-240-140-HSAMLCDFigure 30.240 [6.1mm]0.220 [5.6mm]0.020 [0.5mm]0.140 [3.6mm]
L-65951-240-150-HSAMLCDFigure 30.240 [6.1mm]0.220 [5.6mm]0.020 [0.5mm]0.150 [3.8mm]
L-65951-240-160-HSAMLCDFigure 30.240 [6.1mm]0.220 [5.6mm]0.020 [0.5mm]0.160 [4.1mm]
L-65951-240-170-HSAMLCDFigure 30.240 [6.1mm]0.220 [5.6mm]0.020 [0.5mm]0.170 [4.3mm]
L-65951-240-180-HSAMLCDFigure 30.240 [6.1mm]0.220 [5.6mm]0.020 [0.5mm]0.180 [4.6mm]
L-65951-240-190-HSAMLCDFigure 30.240 [6.1mm]0.220 [5.6mm]0.020 [0.5mm]0.190 [4.8mm]
L-65951-240-200-HSAMLCDFigure 30.240 [6.1mm]0.220 [5.6mm]0.020 [0.5mm]0.200 [5.1mm]
L-65951-250-120-HSAMLCDFigure 30.250 [6.3mm]0.230 [5.8mm]0.020 [0.5mm]0.120 [3.0mm]
L-65951-250-130-HSAMLCDFigure 30.250 [6.3mm]0.230 [5.8mm]0.020 [0.5mm]0.130 [3.3mm]
L-65951-250-140-HSAMLCDFigure 30.250 [6.3mm]0.230 [5.8mm]0.020 [0.5mm]0.140 [3.6mm]
L-65951-250-150-HSAMLCDFigure 30.250 [6.3mm]0.230 [5.8mm]0.020 [0.5mm]0.150 [3.8mm]
L-65951-250-160-HSAMLCDFigure 30.250 [6.3mm]0.230 [5.8mm]0.020 [0.5mm]0.160 [4.1mm]
L-65951-250-170-HSAMLCDFigure 30.250 [6.3mm]0.230 [5.8mm]0.020 [0.5mm]0.170 [4.3mm]
L-65951-250-180-HSAMLCDFigure 30.250 [6.3mm]0.230 [5.8mm]0.020 [0.5mm]0.180 [4.6mm]
L-65951-250-190-HSAMLCDFigure 30.250 [6.3mm]0.230 [5.8mm]0.020 [0.5mm]0.190 [4.8mm]
L-65951-250-200-HSAMLCDFigure 30.250 [6.3mm]0.230 [5.8mm]0.020 [0.5mm]0.200 [5.1mm]
L-65951-280-120-HSAMLCDFigure 30.280 [7.1mm]0.260 [6.6mm]0.020 [0.5mm]0.120 [3.0mm]
L-65951-280-130-HSAMLCDFigure 30.280 [7.1mm]0.260 [6.6mm]0.020 [0.5mm]0.130 [3.3mm]
L-65951-280-140-HSAMLCDFigure 30.280 [7.1mm]0.260 [6.6mm]0.020 [0.5mm]0.140 [3.6mm]
L-65951-280-150-HSAMLCDFigure 30.280 [7.1mm]0.260 [6.6mm]0.020 [0.5mm]0.150 [3.8mm]
L-65951-280-160-HSAMLCDFigure 30.280 [7.1mm]0.260 [6.6mm]0.020 [0.5mm]0.160 [4.1mm]
L-65951-280-170-HSAMLCDFigure 30.280 [7.1mm]0.260 [6.6mm]0.020 [0.5mm]0.170 [4.3mm]
L-65951-280-180-HSAMLCDFigure 30.280 [7.1mm]0.260 [6.6mm]0.020 [0.5mm]0.180 [4.6mm]
L-65951-280-190-HSAMLCDFigure 30.280 [7.1mm]0.260 [6.6mm]0.020 [0.5mm]0.190 [4.8mm]
L-65951-280-200-HSAMLCDFigure 30.280 [7.1mm]0.260 [6.6mm]0.020 [0.5mm]0.200 [5.1mm]
L-65401-185-120-HSYellow Class AFigure 30.185 [4.7mm]0.105 [2.7mm]0.040 [1.1mm]0.120 [3.0mm]
L-65401-185-130-HSYellow Class AFigure 30.185 [4.7mm]0.105 [2.7mm]0.040 [1.1mm]0.130 [3.3mm]
L-65401-185-140-HSYellow Class AFigure 30.185 [4.7mm]0.105 [2.7mm]0.040 [1.1mm]0.140 [3.6mm]
L-65401-185-150-HSYellow Class AFigure 30.185 [4.7mm]0.105 [2.7mm]0.040 [1.1mm]0.150 [3.8mm]
L-65401-185-160-HSYellow Class AFigure 30.185 [4.7mm]0.105 [2.7mm]0.040 [1.1mm]0.160 [4.1mm]
L-65401-185-170-HSYellow Class AFigure 30.185 [4.7mm]0.105 [2.7mm]0.040 [1.1mm]0.170 [4.3mm]
L-65401-185-180-HSYellow Class AFigure 30.185 [4.7mm]0.105 [2.7mm]0.040 [1.1mm]0.180 [4.6mm]
L-65401-185-190-HSYellow Class AFigure 30.185 [4.7mm]0.105 [2.7mm]0.040 [1.1mm]0.190 [4.8mm]
L-65401-185-200-HSYellow Class AFigure 30.185 [4.7mm]0.105 [2.7mm]0.040 [1.1mm]0.200 [5.1mm]
L-65401-210-120-HSYellow Class AFigure 30.210 [5.3mm]0.130 [3.3mm]0.040 [1.1mm]0.120 [3.0mm]
L-65401-210-130-HSYellow Class AFigure 30.210 [5.3mm]0.130 [3.3mm]0.040 [1.1mm]0.130 [3.3mm]
L-65401-210-140-HSYellow Class AFigure 30.210 [5.3mm]0.130 [3.3mm]0.040 [1.1mm]0.140 [3.6mm]
L-65401-210-150-HSYellow Class AFigure 30.210 [5.3mm]0.130 [3.3mm]0.040 [1.1mm]0.150 [3.8mm]
L-65401-210-160-HSYellow Class AFigure 30.210 [5.3mm]0.130 [3.3mm]0.040 [1.1mm]0.160 [4.1mm]
L-65401-210-170-HSYellow Class AFigure 30.210 [5.3mm]0.130 [3.3mm]0.040 [1.1mm]0.170 [4.3mm]
L-65401-210-180-HSYellow Class AFigure 30.210 [5.3mm]0.130 [3.3mm]0.040 [1.1mm]0.180 [4.6mm]
L-65401-210-190-HSYellow Class AFigure 30.210 [5.3mm]0.130 [3.3mm]0.040 [1.1mm]0.190 [4.8mm]
L-65401-210-200-HSYellow Class AFigure 30.210 [5.3mm]0.130 [3.3mm]0.040 [1.1mm]0.200 [5.1mm]
L-65401-240-120-HSYellow Class AFigure 30.240 [6.1mm]0.160 [4.1mm]0.040 [1.1mm]0.120 [3.0mm]
L-65401-240-130-HSYellow Class AFigure 30.240 [6.1mm]0.160 [4.1mm]0.040 [1.1mm]0.130 [3.3mm]
L-65401-240-140-HSYellow Class AFigure 30.240 [6.1mm]0.160 [4.1mm]0.040 [1.1mm]0.140 [3.6mm]
L-65401-240-150-HSYellow Class AFigure 30.240 [6.1mm]0.160 [4.1mm]0.040 [1.1mm]0.150 [3.8mm]
L-65401-240-160-HSYellow Class AFigure 30.240 [6.1mm]0.160 [4.1mm]0.040 [1.1mm]0.160 [4.1mm]
L-65401-240-170-HSYellow Class AFigure 30.240 [6.1mm]0.160 [4.1mm]0.040 [1.1mm]0.170 [4.3mm]
L-65401-240-180-HSYellow Class AFigure 30.240 [6.1mm]0.160 [4.1mm]0.040 [1.1mm]0.180 [4.6mm]
L-65401-240-190-HSYellow Class AFigure 30.240 [6.1mm]0.160 [4.1mm]0.040 [1.1mm]0.190 [4.8mm]
L-65401-240-200-HSYellow Class AFigure 30.240 [6.1mm]0.160 [4.1mm]0.040 [1.1mm]0.200 [5.1mm]
L-65401-250-120-HSYellow Class AFigure 30.250 [6.3mm]0.170 [4.3mm]0.040 [1.1mm]0.120 [3.0mm]
L-65401-250-130-HSYellow Class AFigure 30.250 [6.3mm]0.170 [4.3mm]0.040 [1.1mm]0.130 [3.3mm]
L-65401-250-140-HSYellow Class AFigure 30.250 [6.3mm]0.170 [4.3mm]0.040 [1.1mm]0.140 [3.6mm]
L-65401-250-150-HSYellow Class AFigure 30.250 [6.3mm]0.170 [4.3mm]0.040 [1.1mm]0.150 [3.8mm]
L-65401-250-160-HSYellow Class AFigure 30.250 [6.3mm]0.170 [4.3mm]0.040 [1.1mm]0.160 [4.1mm]
L-65401-250-170-HSYellow Class AFigure 30.250 [6.3mm]0.170 [4.3mm]0.040 [1.1mm]0.170 [4.3mm]
L-65401-250-180-HSYellow Class AFigure 30.250 [6.3mm]0.170 [4.3mm]0.040 [1.1mm]0.180 [4.6mm]
L-65401-250-190-HSYellow Class AFigure 30.250 [6.3mm]0.170 [4.3mm]0.040 [1.1mm]0.190 [4.8mm]
L-65401-250-200-HSYellow Class AFigure 30.250 [6.3mm]0.170 [4.3mm]0.040 [1.1mm]0.200 [5.1mm]
L-65401-280-120-HSYellow Class AFigure 30.280 [7.1mm]0.200 [5.1mm]0.040 [1.1mm]0.120 [3.0mm]
L-65401-280-130-HSYellow Class AFigure 30.280 [7.1mm]0.200 [5.1mm]0.040 [1.1mm]0.130 [3.3mm]
L-65401-280-140-HSYellow Class AFigure 30.280 [7.1mm]0.200 [5.1mm]0.040 [1.1mm]0.140 [3.6mm]
L-65401-280-150-HSYellow Class AFigure 30.280 [7.1mm]0.200 [5.1mm]0.040 [1.1mm]0.150 [3.8mm]
L-65401-280-160-HSYellow Class AFigure 30.280 [7.1mm]0.200 [5.1mm]0.040 [1.1mm]0.160 [4.1mm]
L-65401-280-170-HSYellow Class AFigure 30.280 [7.1mm]0.200 [5.1mm]0.040 [1.1mm]0.170 [4.3mm]
L-65401-280-180-HSYellow Class AFigure 30.280 [7.1mm]0.200 [5.1mm]0.040 [1.1mm]0.180 [4.6mm]
L-65401-280-190-HSYellow Class AFigure 30.280 [7.1mm]0.200 [5.1mm]0.040 [1.1mm]0.190 [4.8mm]
L-65401-280-200-HSYellow Class AFigure 30.280 [7.1mm]0.200 [5.1mm]0.040 [1.1mm]0.200 [5.1mm]
L-65402-185-120-HSYellow Class BFigure 30.185 [4.7mm]0.105 [2.7mm]0.040 [1.1mm]0.120 [3.0mm]
L-65402-185-130-HSYellow Class BFigure 30.185 [4.7mm]0.105 [2.7mm]0.040 [1.1mm]0.130 [3.3mm]
L-65402-185-140-HSYellow Class BFigure 30.185 [4.7mm]0.105 [2.7mm]0.040 [1.1mm]0.140 [3.6mm]
L-65402-185-150-HSYellow Class BFigure 30.185 [4.7mm]0.105 [2.7mm]0.040 [1.1mm]0.150 [3.8mm]
L-65402-185-160-HSYellow Class BFigure 30.185 [4.7mm]0.105 [2.7mm]0.040 [1.1mm]0.160 [4.1mm]
L-65402-185-170-HSYellow Class BFigure 30.185 [4.7mm]0.105 [2.7mm]0.040 [1.1mm]0.170 [4.3mm]
L-65402-185-180-HSYellow Class BFigure 30.185 [4.7mm]0.105 [2.7mm]0.040 [1.1mm]0.180 [4.6mm]
L-65402-185-190-HSYellow Class BFigure 30.185 [4.7mm]0.105 [2.7mm]0.040 [1.1mm]0.190 [4.8mm]
L-65402-185-200-HSYellow Class BFigure 30.185 [4.7mm]0.105 [2.7mm]0.040 [1.1mm]0.200 [5.1mm]
L-65402-210-120-HSYellow Class BFigure 30.210 [5.3mm]0.130 [3.3mm]0.040 [1.1mm]0.120 [3.0mm]
L-65402-210-130-HSYellow Class BFigure 30.210 [5.3mm]0.130 [3.3mm]0.040 [1.1mm]0.130 [3.3mm]
L-65402-210-140-HSYellow Class BFigure 30.210 [5.3mm]0.130 [3.3mm]0.040 [1.1mm]0.140 [3.6mm]
L-65402-210-150-HSYellow Class BFigure 30.210 [5.3mm]0.130 [3.3mm]0.040 [1.1mm]0.150 [3.8mm]
L-65402-210-160-HSYellow Class BFigure 30.210 [5.3mm]0.130 [3.3mm]0.040 [1.1mm]0.160 [4.1mm]
L-65402-210-170-HSYellow Class BFigure 30.210 [5.3mm]0.130 [3.3mm]0.040 [1.1mm]0.170 [4.3mm]
L-65402-210-180-HSYellow Class BFigure 30.210 [5.3mm]0.130 [3.3mm]0.040 [1.1mm]0.180 [4.6mm]
L-65402-210-190-HSYellow Class BFigure 30.210 [5.3mm]0.130 [3.3mm]0.040 [1.1mm]0.190 [4.8mm]
L-65402-210-200-HSYellow Class BFigure 30.210 [5.3mm]0.130 [3.3mm]0.040 [1.1mm]0.200 [5.1mm]
L-65402-240-120-HSYellow Class BFigure 30.240 [6.1mm]0.160 [4.1mm]0.040 [1.1mm]0.120 [3.0mm]
L-65402-240-130-HSYellow Class BFigure 30.240 [6.1mm]0.160 [4.1mm]0.040 [1.1mm]0.130 [3.3mm]
L-65402-240-140-HSYellow Class BFigure 30.240 [6.1mm]0.160 [4.1mm]0.040 [1.1mm]0.140 [3.6mm]
L-65402-240-150-HSYellow Class BFigure 30.240 [6.1mm]0.160 [4.1mm]0.040 [1.1mm]0.150 [3.8mm]
L-65402-240-160-HSYellow Class BFigure 30.240 [6.1mm]0.160 [4.1mm]0.040 [1.1mm]0.160 [4.1mm]
L-65402-240-170-HSYellow Class BFigure 30.240 [6.1mm]0.160 [4.1mm]0.040 [1.1mm]0.170 [4.3mm]
L-65402-240-180-HSYellow Class BFigure 30.240 [6.1mm]0.160 [4.1mm]0.040 [1.1mm]0.180 [4.6mm]
L-65402-240-190-HSYellow Class BFigure 30.240 [6.1mm]0.160 [4.1mm]0.040 [1.1mm]0.190 [4.8mm]
L-65402-240-200-HSYellow Class BFigure 30.240 [6.1mm]0.160 [4.1mm]0.040 [1.1mm]0.200 [5.1mm]
L-65402-250-120-HSYellow Class BFigure 30.250 [6.3mm]0.170 [4.3mm]0.040 [1.1mm]0.120 [3.0mm]
L-65402-250-130-HSYellow Class BFigure 30.250 [6.3mm]0.170 [4.3mm]0.040 [1.1mm]0.130 [3.3mm]
L-65402-250-140-HSYellow Class BFigure 30.250 [6.3mm]0.170 [4.3mm]0.040 [1.1mm]0.140 [3.6mm]
L-65402-250-150-HSYellow Class BFigure 30.250 [6.3mm]0.170 [4.3mm]0.040 [1.1mm]0.150 [3.8mm]
L-65402-250-160-HSYellow Class BFigure 30.250 [6.3mm]0.170 [4.3mm]0.040 [1.1mm]0.160 [4.1mm]
L-65402-250-170-HSYellow Class BFigure 30.250 [6.3mm]0.170 [4.3mm]0.040 [1.1mm]0.170 [4.3mm]
L-65402-250-180-HSYellow Class BFigure 30.250 [6.3mm]0.170 [4.3mm]0.040 [1.1mm]0.180 [4.6mm]
L-65402-250-190-HSYellow Class BFigure 30.250 [6.3mm]0.170 [4.3mm]0.040 [1.1mm]0.190 [4.8mm]
L-65402-250-200-HSYellow Class BFigure 30.250 [6.3mm]0.170 [4.3mm]0.040 [1.1mm]0.200 [5.1mm]
L-65402-280-120-HSYellow Class BFigure 30.280 [7.1mm]0.200 [5.1mm]0.040 [1.1mm]0.120 [3.0mm]
L-65402-280-130-HSYellow Class BFigure 30.280 [7.1mm]0.200 [5.1mm]0.040 [1.1mm]0.130 [3.3mm]
L-65402-280-140-HSYellow Class BFigure 30.280 [7.1mm]0.200 [5.1mm]0.040 [1.1mm]0.140 [3.6mm]
L-65402-280-150-HSYellow Class BFigure 30.280 [7.1mm]0.200 [5.1mm]0.040 [1.1mm]0.150 [3.8mm]
L-65402-280-160-HSYellow Class BFigure 30.280 [7.1mm]0.200 [5.1mm]0.040 [1.1mm]0.160 [4.1mm]
L-65402-280-170-HSYellow Class BFigure 30.280 [7.1mm]0.200 [5.1mm]0.040 [1.1mm]0.170 [4.3mm]
L-65402-280-180-HSYellow Class BFigure 30.280 [7.1mm]0.200 [5.1mm]0.040 [1.1mm]0.180 [4.6mm]
L-65402-280-190-HSYellow Class BFigure 30.280 [7.1mm]0.200 [5.1mm]0.040 [1.1mm]0.190 [4.8mm]
L-65402-280-200-HSYellow Class BFigure 30.280 [7.1mm]0.200 [5.1mm]0.040 [1.1mm]0.200 [5.1mm]
L-65403-185-120-HSRed Class BFigure 30.185 [4.7mm]0.105 [2.7mm]0.020 [0.5mm]0.120 [3.0mm]
L-65403-185-130-HSRed Class BFigure 30.185 [4.7mm]0.105 [2.7mm]0.020 [0.5mm]0.130 [3.3mm]
L-65403-185-140-HSRed Class BFigure 30.185 [4.7mm]0.105 [2.7mm]0.020 [0.5mm]0.140 [3.6mm]
L-65403-185-150-HSRed Class BFigure 30.185 [4.7mm]0.105 [2.7mm]0.020 [0.5mm]0.150 [3.8mm]
L-65403-185-160-HSRed Class BFigure 30.185 [4.7mm]0.105 [2.7mm]0.020 [0.5mm]0.160 [4.1mm]
L-65403-185-170-HSRed Class BFigure 30.185 [4.7mm]0.105 [2.7mm]0.020 [0.5mm]0.170 [4.3mm]
L-65403-185-180-HSRed Class BFigure 30.185 [4.7mm]0.105 [2.7mm]0.020 [0.5mm]0.180 [4.6mm]
L-65403-185-190-HSRed Class BFigure 30.185 [4.7mm]0.105 [2.7mm]0.020 [0.5mm]0.190 [4.8mm]
L-65403-185-200-HSRed Class BFigure 30.185 [4.7mm]0.105 [2.7mm]0.020 [0.5mm]0.200 [5.1mm]
L-65403-210-120-HSRed Class BFigure 30.210 [5.3mm]0.130 [3.3mm]0.020 [0.5mm]0.120 [3.0mm]
L-65403-210-130-HSRed Class BFigure 30.210 [5.3mm]0.130 [3.3mm]0.020 [0.5mm]0.130 [3.3mm]
L-65403-210-140-HSRed Class BFigure 30.210 [5.3mm]0.130 [3.3mm]0.020 [0.5mm]0.140 [3.6mm]
L-65403-210-150-HSRed Class BFigure 30.210 [5.3mm]0.130 [3.3mm]0.020 [0.5mm]0.150 [3.8mm]
L-65403-210-160-HSRed Class BFigure 30.210 [5.3mm]0.130 [3.3mm]0.020 [0.5mm]0.160 [4.1mm]
L-65403-210-170-HSRed Class BFigure 30.210 [5.3mm]0.130 [3.3mm]0.020 [0.5mm]0.170 [4.3mm]
L-65403-210-180-HSRed Class BFigure 30.210 [5.3mm]0.130 [3.3mm]0.020 [0.5mm]0.180 [4.6mm]
L-65403-210-190-HSRed Class BFigure 30.210 [5.3mm]0.130 [3.3mm]0.020 [0.5mm]0.190 [4.8mm]
L-65403-210-200-HSRed Class BFigure 30.210 [5.3mm]0.130 [3.3mm]0.020 [0.5mm]0.200 [5.1mm]
L-65403-240-120-HSRed Class BFigure 30.240 [6.1mm]0.160 [4.1mm]0.020 [0.5mm]0.120 [3.0mm]
L-65403-240-130-HSRed Class BFigure 30.240 [6.1mm]0.160 [4.1mm]0.020 [0.5mm]0.130 [3.3mm]
L-65403-240-140-HSRed Class BFigure 30.240 [6.1mm]0.160 [4.1mm]0.020 [0.5mm]0.140 [3.6mm]
L-65403-240-150-HSRed Class BFigure 30.240 [6.1mm]0.160 [4.1mm]0.020 [0.5mm]0.150 [3.8mm]
L-65403-240-160-HSRed Class BFigure 30.240 [6.1mm]0.160 [4.1mm]0.020 [0.5mm]0.160 [4.1mm]
L-65403-240-170-HSRed Class BFigure 30.240 [6.1mm]0.160 [4.1mm]0.020 [0.5mm]0.170 [4.3mm]
L-65403-240-180-HSRed Class BFigure 30.240 [6.1mm]0.160 [4.1mm]0.020 [0.5mm]0.180 [4.6mm]
L-65403-240-190-HSRed Class BFigure 30.240 [6.1mm]0.160 [4.1mm]0.020 [0.5mm]0.190 [4.8mm]
L-65403-240-200-HSRed Class BFigure 30.240 [6.1mm]0.160 [4.1mm]0.020 [0.5mm]0.200 [5.1mm]
L-65403-250-120-HSRed Class BFigure 30.250 [6.3mm]0.170 [4.3mm]0.020 [0.5mm]0.120 [3.0mm]
L-65403-250-130-HSRed Class BFigure 30.250 [6.3mm]0.170 [4.3mm]0.020 [0.5mm]0.130 [3.3mm]
L-65403-250-140-HSRed Class BFigure 30.250 [6.3mm]0.170 [4.3mm]0.020 [0.5mm]0.140 [3.6mm]
L-65403-250-150-HSRed Class BFigure 30.250 [6.3mm]0.170 [4.3mm]0.020 [0.5mm]0.150 [3.8mm]
L-65403-250-160-HSRed Class BFigure 30.250 [6.3mm]0.170 [4.3mm]0.020 [0.5mm]0.160 [4.1mm]
L-65403-250-170-HSRed Class BFigure 30.250 [6.3mm]0.170 [4.3mm]0.020 [0.5mm]0.170 [4.3mm]
L-65403-250-180-HSRed Class BFigure 30.250 [6.3mm]0.170 [4.3mm]0.020 [0.5mm]0.180 [4.6mm]
L-65403-250-190-HSRed Class BFigure 30.250 [6.3mm]0.170 [4.3mm]0.020 [0.5mm]0.190 [4.8mm]
L-65403-250-200-HSRed Class BFigure 30.250 [6.3mm]0.170 [4.3mm]0.020 [0.5mm]0.200 [5.1mm]
L-65403-280-120-HSRed Class BFigure 30.280 [7.1mm]0.200 [5.1mm]0.020 [0.5mm]0.120 [3.0mm]
L-65403-280-130-HSRed Class BFigure 30.280 [7.1mm]0.200 [5.1mm]0.020 [0.5mm]0.130 [3.3mm]
L-65403-280-140-HSRed Class BFigure 30.280 [7.1mm]0.200 [5.1mm]0.020 [0.5mm]0.140 [3.6mm]
L-65403-280-150-HSRed Class BFigure 30.280 [7.1mm]0.200 [5.1mm]0.020 [0.5mm]0.150 [3.8mm]
L-65403-280-160-HSRed Class BFigure 30.280 [7.1mm]0.200 [5.1mm]0.020 [0.5mm]0.160 [4.1mm]
L-65403-280-170-HSRed Class BFigure 30.280 [7.1mm]0.200 [5.1mm]0.020 [0.5mm]0.170 [4.3mm]
L-65403-280-180-HSRed Class BFigure 30.280 [7.1mm]0.200 [5.1mm]0.020 [0.5mm]0.180 [4.6mm]
L-65403-280-190-HSRed Class BFigure 30.280 [7.1mm]0.200 [5.1mm]0.020 [0.5mm]0.190 [4.8mm]
L-65403-280-200-HSRed Class BFigure 30.280 [7.1mm]0.200 [5.1mm]0.020 [0.5mm]0.200 [5.1mm]

Specification Tables

Ordering Information

L-65xxx-xxx-xxx Designates an optical filter for light emitting diodes (LED)

L-65196-xxx-xxx The next three numbers designate the filter color per the Color Table (L-65196 = NVIS Green A)

L-65196-185-xxx The middle numbers call out the Outside Diameter (L-65196-185-xxx = Ø0.185 [4.7] Monolithic)

L-65196-185-160 – The last three numbers designate the Overall Length D Dimension per the Length Table (160 = 0.160 [4.1mm])

Example Figure 1:  L-65196-185-160 is a Monolithic NVIS Green A ring filter , Ø 0.185 [4.7] x 0.160 [4.1mm]

Example Figure 2:  L-65196-185-160-D is a Monolithic Dome NVIS Green A ring filter , Ø 0.185 [4.7] x 0.160 [4.1mm]

Example Figure 3:  L-65196-185-160-HS is a NVIS Green A ring filter with Heat Sink , Ø 0.185 [4.7] x 0.160 [4.1mm]

PLEASE NOTE: Custom ring filters per customer dimensional specifications are available. Contact Lumitron with your requirements.

Application Notes

PolyVision optical filters are subject to the following thermal constraints:

1. Intermittent Use Temperature: 190C

2. Extended Use Temperature: 120C

Table Notes

Dimensions are in inches [mm].  Part Number Table can be sorted by clicking column headers. Use search window to customize table output, and to create or confirm valid part numbers.

Request Data Sheet for PolyVision Ring Filters for LEDs

Lighting...Your Way!

Call 908.508.9100 or email us at sales@lumitron.com with your product questions or to place an order.

Contact Us
